Mobile Platform as a Service:Style syntax

In template mode, you can apply styles to components within the <template></template> section using classes. For example, <text class="mytext">✅.

CSS styles

The `class`, `id`, and `type` selectors are supported. More complex combinations, such as parent-child or state selectors, are not supported. The following code shows examples of the three supported selectors:

// class
.class {
}

// id
#id {
}

// type
div {
}

Inline styles

Template mode lets you inject styles at runtime using the built-in style field of a component.

The syntax for inline styles is the same as in popular frontend frameworks, such as VueJS and ReactJS. Both bound and non-bound formats are supported.

• Bound inline styles

  • You can group the style fields for binding into a single JSONObject.

  • The keys for the style fields must be in camelCase. For example, you must convert `background-color` to `backgroundColor`.

• Non-bound inline styles

  • You can group the style fields for binding into a single string that follows CSS syntax.

  • The keys for the style fields must use hyphen-separated words as specified in CSS, for example, `background-color`.

The order of style priority from highest to lowest is inline style, id, class, and type.

// main.vue
<template>
  <div class="root">
    <div class="div1" :style="style"></div>
    <div class="div2" style="width: 100px; background-color: blue"></div>
  </div>
</template>

// mock.json
{
  "style": {
    "height": "100px",
    "backgroundColor": "red"
  }
}

For inline styles, the template accepts a JavaScript (JS) object as the attribute value.

<div class="root" :style="{height: height}"> // Example from above

Dynamic class binding

You can dynamically bind different selectors to a component's CSS styles.

<div :class="mydiv">

Media queries (@media)

Template mode includes the media query feature from the CSS specification. This feature is mainly used for mobile UI adaptation.

The media query capabilities in template mode are more limited than those in the CSS specification and require specific usage patterns as described in the following sections. For more information about media queries, see Introduction to @media.

• Media types

  You do not need to specify the media type. The default value is `all`.

  Media type	Supported
  all	Yes
  screen	No
  print	No
  speech	No

• Media features

  In cards, media features are based on firmware attributes, which is different from how they work in frontend browsers.

  Media feature	Value	Description
  platform	ios | android	Adapts to a specific platform. The usage differs from the CSS specification. Set the platform value directly after `@media`. For example, `@media android`.
  support	safearea	Adapts to the screen security zone on the iOS platform.

• Media operators

  Operator	Support
  and	Yes
  not	No
  only	No

The following example shows how to adapt styles by combining CSS attributes and `@media` queries.

<template>
    <div class="banner"></div>
</template>
<style>
    @media android {
        .banner {
                  width: 100px;
                        height: 100px;
            background-color: #00fff0;
        }
    }
    @media ios and (support: safearea) {
        .banner {
            width: 100px;
                        height: 100px;
            background-color: #00fafb;
        }
    }
    .banner {
              width: 100px;
        height: 100px;
        background-color: green;
    }
</style>

Importing styles

Before you import styles, you need to understand the following two types of styles:

• Imported styles: These are styles in a .css file that can be centrally managed and imported.

• Scoped styles: These are styles in the <style></style> section of a .vue file that apply only to that template.

Syntax format

The syntax for importing styles is as follows:

<style src="[relative path to .css file]" />

• File structure

.
└── template_name                                                 // Template folder (named after the template ID)
    ├── main.vue                                                       // Template layout and style description file
    ├── manifest.json                                                // Template configuration file
    └── mock.json                                                     // Test data for template binding
    └── common.css                                                 // Common template style file

• Template code

<template>
        ... [Template layout description]
</template>

<style src="./common.css" />

<style>
        ... [Styles that apply only to this template]
</style>

Cascading rules

When compiling style resources in a .vue file, template mode cascades and merges only style fields that share the same selector. Different selectors remain unchanged.

The cascaded result is a combination of imported styles and scoped styles, as shown in the following table.

.special {
 color: red;
 width: 100px;
}
.others {
 color: red;
 width: 100px;
}

.special {
 background-color: red;
 width: 200px;
}
.scoped {
 background-color: red;
 width: 200px;
}

.special {
 color: red;
 background-color: red;
 width: 200px;
}
.scoped {
 background-color: red;
 width: 200px;
}
.others {
 color: red;
 width: 100px;
}

Code example

You can download the FalconDemo code example.
