DataWorks:Use Hologres dynamic tables

Prerequisites

• A workspace is created, the Use Data Studio (New Version) option is selected, and a resource group is attached to the workspace. For more information, see Create a workspace.

• A Hologres data source is created. For more information, see Attach a Hologres computing resource.

• A Hologres computing resource is attached to the workspace and has passed the connectivity test. For more information, see Attach a computing resource.

Limits

• The Hologres instance must be V3.0.18 or later.

• For more information about the limits of dynamic tables, see Dynamic Table supported features and limits.

Prepare data

Create a test table and add test data to your Hologres instance. The following code provides an example:

CREATE  TABLE  tb_order(
    order_id int PRIMARY KEY,
    title VARCHAR(255),
    price FLOAT ,
    payment FLOAT ,
    order_time TIMESTAMP
)WITH (
    orientation = 'row',
    clustering_key = 'order_id',
    binlog_level = 'replica',
    binlog_ttl = '86400'
);

INSERT INTO tb_order SELECT 1252555,'book',12.36,12.36,'2024-12-19 09:00:05';
INSERT INTO tb_order SELECT 1252556,'pen',22.36,22.36,'2024-12-19 17:00:05';
INSERT INTO tb_order SELECT 1252557,'role',36.36,36.36,'2024-12-19 17:10:05';

Go to the data catalog

1. Go to the Workspaces page in the DataWorks console. In the top navigation bar, select a desired region. Find the desired workspace and choose Shortcuts > Data Studio in the Actions column.

2. In the left navigation pane, click the icon to go to the Data Catalog.

Create a dynamic table

1. In the Data Catalog area, find the target Hologres instance, expand the directories, and click the icon to the right of Dynamic Table to open the Create Dynamic Table page.

   Note

   • If you use a workspace in standard mode, a Development database instance and a Production database instance are listed under the Hologres Data Catalog. We recommend that you first create and test the Hologres dynamic table in the development database. After you confirm that the table works as expected, you can create it in the production environment.

   • In a workspace in standard mode, dynamic tables that you create in the development database are not automatically synchronized to the production database. To query and use these tables in the production database, you must create the same Hologres dynamic tables in the production database.



2. On the Create Dynamic Table page, perform the following steps to create the dynamic table.

   1. In the Basic Information section, configure the parameters.

      Specify the Table Name and Description for the dynamic table.

   2. In the Field Information section, configure the settings.

      1. In the Field Information area on the SQL Development tab, add the following sample code to the editor.

         SELECT
             t.order_id,
             t.title,
             t.price,
             t.day_time,
             COUNT(*) AS order_num
         FROM (
             SELECT
                 order_id,
                 title,
                 price,
                 EXTRACT(DAY FROM order_time) AS day_time
             FROM tb_order
             WHERE order_time >= NOW() - INTERVAL '1 hour'
         ) AS t
         GROUP BY
             t.order_id,
             t.title,
             t.price,
             t.day_time;

      2. After you add the code, click Precompile above the editor. The Hologres DPI engine compiles the SQL statement to check for errors and determine which dynamic table patterns are compatible.

      3. After the precompilation succeeds, click the Field Details tab in the Field Information area to add a Description to the dynamic table.

   3. Partition Field Selection.

      After you configure the Field Information, select a partition field from the Partition Field drop-down list under Partition Field Information. If you do not select a field, the system creates a non-partitioned dynamic table by default. The data refresh methods and configurations are different for non-partitioned and partitioned dynamic tables:

      • Data refresh for non-partitioned dynamic tables: Data in a non-partitioned dynamic table is automatically refreshed either by a DataWorks recurring schedule or by the Hologres engine.

      • Data refresh for partitioned dynamic tables: The data refresh lifecycle includes the following phases: Pre-create partitions, Start partition refresh, End partition refresh, and Refresh partition data.

      • The parameters for the data refresh policy are different for non-partitioned and partitioned dynamic tables. For more information, see Configure a data refresh policy.

   4. In the Advanced Settings section, configure the parameters.

      Configure the parameters for the dynamic table.

      Parameter	Description
      Storage Mode	Hologres supports three storage modes: Column Store, Row Store, and Row-Column Hybrid Store. The default mode is Column Store. For more information, see Table storage formats: column store, row store, and row-column hybrid store. Column store is suitable for complex queries in various Online Analytical Processing (OLAP) scenarios. Row store is suitable for key-value (KV) query scenarios based on primary keys. Row-column hybrid store is suitable for scenarios where both column store and row store can be used.
      Table Group	Select the name of the Table Group that is generated when you create an internal table in the Hologres data source. For more information, see Manage table groups.
      Storage Policy	Hologres supports two storage policies: Standard storage (Hot Storage) and Infrequent Access storage (Cold Storage). Hot storage, also known as all-SSD hot storage, is the default storage policy in Hologres. It meets the requirements for low-latency, high-performance data access. For most scenarios, Standard storage is the most effective and cost-efficient choice. Cold storage, also known as all-HDD cold storage, meets the requirement for low-cost storage of infrequently accessed data. It is suitable for very large datasets that are not sensitive to latency or are not frequently accessed. For more information, see Tiered storage.
      Table Data Lifecycle	Set a custom maximum time to live for the dynamic table.
      Binlog	Choose to enable (replica) or disable (none) subscription to Hologres binary logs. By default, this feature is disabled. For more information, see Subscribe to Hologres binary logs.
      Binlog Lifecycle	The maximum lifecycle of Hologres binary logs. You can configure this parameter only if you set the Binlog parameter to replica. For more information, see Subscribe to Hologres binary logs.
      Field Properties	Set the field properties. This includes selecting the Distribution Column, Segment Column, Clustering Column, Bitmap Column, and Dictionary Encoding Column for a Field Name. Configure the properties based on the descriptions on the page. For more information, see Manage internal tables.

3. Publish the dynamic table.

   On the right side of the page, click Refresh Policy. On the data refresh policy page, configure the data refresh policy and select your Schedule Resource Group under Dependency Configurations. To publish the new Hologres dynamic table, click Publish at the top of the page.

   Note

   When you create a partitioned dynamic table, the View Partition Example dialog box opens. Select Day Partition or Hour Partition according to your data refresh policy, and then click Publish.

View a dynamic table

After you publish a Hologres dynamic table, go to the Data Catalog area. Find the destination Hologres instance under the Hologres type, expand the directories, and click Dynamic Table. In the list that appears, find the dynamic table you created and click its name to view the details.

• You can view the details.

  On the Details tab, you can view the Table Fields and Partition Fields of the dynamic table.

• You can view the basic information.

  On the Basic Information tab, you can view the Basic Properties, Data Refresh Logic-SQL, Data Refresh Policy, and Advanced Properties of the dynamic table.

• You can view DDL information.

  On the DDL tab, you can view and copy the DDL of the dynamic table.

• View the output.

  On the Output Information tab, you can view the output data from the dynamic table.

  Note

  • If you create a non-partitioned dynamic table, you can view the output information of the table.

  • If you create a partitioned dynamic table, the primary table is a logical table and does not have output information. Click the icon to the left of the partitioned dynamic table to expand the child partitioned tables and view their output information.

Delete a dynamic table

To delete a Hologres dynamic table, find the target Hologres instance in the Data Catalog area. Expand the directories. Right-click the target dynamic table under Dynamic Table and select Delete. In the confirmation dialog box, click Confirm.

Before deleting a Hologres dynamic table, DataWorks first attempts to delete the associated scheduling task. If the task has downstream dependencies, the deletion fails. You must go to the Operation Center, manually detach the downstream dependencies, and then delete the table.

Configure a data refresh policy

The parameters for the data refresh policy differ for non-partitioned and partitioned dynamic tables. Configure the policy as described in the following sections.
