Try the ApsaraVideo MediaBox SDK demo - Apsara Video SDK

The ApsaraVideo MediaBox SDK demo showcases best practices for the end-to-end ApsaraVideo workflow, demonstrating playback, short video, and stream ingest. You can scan the QR code to install and try the demo on your phone, or download the source code to build and run it locally.

Important

The built-in resource download service is a temporary service set up by Alibaba Cloud. Its availability and stability are not guaranteed. This service is for demonstration purposes only and must not be used in a commercial production environment.
If you plan to use the application for commercial purposes, you must modify it to use your own resource download server. Alibaba Cloud does not provide any functionality related to this resource download address and does not offer support for its implementation.

Try the pre-built demo app

Real-time conversational AI scenario: Enables efficient audio and video interaction between AI and users.
Live streaming scenario: Use cases include e-commerce live streaming, corporate training, co-streaming, and more.
Interactive entertainment & calling scenario: Use cases include voice chat rooms, online karaoke rooms, 1-on-1 calls, group calls, and more.
VOD scenario: Use cases include mini-dramas, feed-based playback, immersive playback, short video creation, and more.

Download and install

Scan the QR code below to download and install the ApsaraVideo MediaBox SDK demo:

p935088

Run the demo source code

Android

Development environment

Item	Description
Android Studio	Download from the official Android Studio website.
Gradle	We recommend Gradle 7.0.2 or later with plugin 4.1.2.
Gradle JDK	We recommend Gradle JDK 11. To configure this, go to Preferences -> Build, Execution, Deployment -> Build Tools -> Gradle -> Gradle JDK and select 11. If 11 is not available in the dropdown list, upgrade your Android Studio.

Runtime environment

Requires a physical device running Android 4.3 or later. Simulators are not supported for debugging.

Run the demo

Clone the demo source code from GitHub and follow the instructions in the latest README file.
Open the demo project in Android Studio.

For security reasons, license authorization on Alibaba Cloud requires an MD5 signature. Use one of the following methods to obtain it:

Search for signingConfigs and configure your signing information.

signingConfigs {
    debug {
        //TODO: Set your signing information. The following is an example.
        storeFile file("$rootDir/xxx")
        storePassword "xxx"
        keyAlias "xxx"
        keyPassword "xxx"
    }
    release {
        //TODO: Set your signing information. The following is an example.
        storeFile file("$rootDir/xxx")
        storePassword "xxx"
        keyAlias "xxx"
        keyPassword "xxx"
    }
}

Method 1: Call the getSingInfo(Context context) method in AUIFoundation/AVUtils/src/main/java/com/aliyun/aio/utils/SignatureUtils.java to get the signature.

Method 2: Download a signing tool to obtain the signature.

Apply for a license for the SDK module you need to test. For more information, see Manage licenses. Obtain the license key and license file.
1. Place the license file in the AIOApp/src/main/assets directory.
2. Open AIOApp/src/main/AndroidManifest.xml. Find com.aliyun.alivc_license.licensekey and com.aliyun.alivc_license.licensefile and change their values to your license key and license file, respectively. For details, see Integrate a license.
Compile and run.

Connect a physical Android device, and then click Run > Run 'app' to compile and run the project.

iOS

Development environment

Item	Description
macOS	macOS High Sierra 10.13 or later.
Xcode	We recommend Xcode 13 or later. The instructions in this guide are for Xcode.
CocoaPods	We recommend CocoaPods 1.10 or later.

Runtime environment

Requires a physical device running iOS 9.0 or later. Simulators are not supported for debugging.

Run the demo

Clone the demo source code from GitHub and follow the instructions in the latest README file.
In the AlivcAIODemo directory, run pod install to install the dependencies.

Note
If the installation fails, run pod install --repo-update.
Open the AlivcAIODemo.xcworkspace project in Xcode.
Apply for a license for the SDK module you need to test. For more information, see Manage licenses. Obtain the license key and license file.
1. Rename the downloaded license file to license.crt and copy it to the AlivcAIODemo directory.
2. Open AlivcAIODemo/Info.plist and set the value of AlivcLicenseKey to your license key. Alternatively, in the Xcode project's Info tab, find Custom iOS Target Properties and set the value of AlivcLicenseKey to your license key.
Compile and run.
