Elastic Compute Service：Audit dan perbaiki secara otomatis aturan grup keamanan yang tidak sesuai

variable "region_id" {
  type    = string
  default = "cn-shenzhen"
}
# main.tf


provider "alicloud" {
  region     = var.region_id
}

resource "local_file" "python_script" {
  content  = <<EOF
#!/usr/bin/env python
# -*- encoding: utf-8 -*-
import sys

sys.path.append('/opt/python')
import json
import logging
import jmespath  # Gunakan jmespath sebagai pengganti jsonpath.
from alibabacloud_tea_openapi import models as open_api_models
from alibabacloud_tea_openapi.client import Client as OpenApiClient
from alibabacloud_openapi_util.client import Client as OpenApiUtilClient
from alibabacloud_tea_util import models as util_models

logger = logging.getLogger()


def handler(event, context):
    logger.info(f"Ini adalah event: {str(event, encoding='utf-8')}")
    get_resources_non_compliant(event, context)


def get_resources_non_compliant(event, context):
    # Dapatkan informasi tentang resource yang tidak sesuai.
    resources = parse_json(event)
    # Lakukan iterasi terhadap resource yang tidak sesuai dan lakukan remediasi.
    for resource in resources:
        remediation(resource, context)


def parse_json(content):
    """
    Uraikan string menjadi objek json
    :param content: konten string json
    :return: Objek Json
    """
    try:
        return json.loads(content)
    except Exception as e:
        logger.error('Gagal mengurai konten:{} menjadi json: {}.'.format(content, e))
        return None


def remediation(resource, context):
    logger.info(f"Informasi tentang resource yang akan diperbaiki: {resource}")
    region_id = resource['regionId']
    account_id = resource['accountId']
    resource_id = resource['resourceId']
    resource_type = resource['resourceType']
    if resource_type == 'ACS::ECS::SecurityGroup':
        # Dapatkan konfigurasi security group yang tidak sesuai dan verifikasi ulang untuk memastikan akurasi penilaian.
        resource_result = get_discovered_resource(context, resource_id, resource_type, region_id)
        configuration = json.loads(resource_result["body"]["DiscoveredResourceDetail"]["Configuration"])
        # Periksa apakah security group tersebut merupakan security group yang dikelola.
        is_managed_security_group = configuration.get('ServiceManaged')
        # Gunakan jmespath untuk mendapatkan ID aturan security group yang memiliki arah inbound dan memberikan akses ke 0.0.0.0/0.
        delete_security_group_rule_ids = jmespath.search(
            "Permissions.Permission[?SourceCidrIp=='0.0.0.0/0'].SecurityGroupRuleId",
            configuration
        )
        # Jika security group bukan security group yang dikelola dan memiliki aturan inbound yang memberikan akses ke 0.0.0.0/0, hapus aturan tersebut.
        if is_managed_security_group is False and delete_security_group_rule_ids:
            logger.info(f"Catatan: Menghapus aturan security group {region_id}:{resource_id}:{delete_security_group_rule_ids}")
            revoke_security_group(context, region_id, resource_id, delete_security_group_rule_ids)


def revoke_security_group(context, region_id, resource_id, security_group_rule_ids):
    creds = context.credentials
    config = open_api_models.Config(
        access_key_id=creds.access_key_id,
        access_key_secret=creds.access_key_secret,
        security_token=creds.security_token,
        endpoint=f'ecs.{region_id}.aliyuncs.com'
    )
    client = OpenApiClient(config)
    params = open_api_models.Params(
        style='RPC',  # Gaya API
        version='2014-05-26',  # Nomor versi API
        action='RevokeSecurityGroup',  # Nama API
        method='POST',  # Metode permintaan
        pathname='/',  # Jalur API. Jalur default untuk API RPC adalah "/".
        protocol='HTTPS',  # Protokol API.
        auth_type='AK',
        req_body_type='json',  # Format badan permintaan.
        body_type='json'  # Format badan respons.
    )
    query = {'RegionId': region_id, 'SecurityGroupId': resource_id, 'SecurityGroupRuleId': security_group_rule_ids}
    # Buat objek permintaan API.
    request = open_api_models.OpenApiRequest(
        query=OpenApiUtilClient.query(query),
    )
    runtime = util_models.RuntimeOptions()
    response = client.call_api(params, request, runtime)
    logger.info(f"Hasil penghapusan: {response}")


# Dapatkan detail resource.
def get_discovered_resource(context, resource_id, resource_type, region_id):
    """
    Panggil operasi API untuk mendapatkan detail konfigurasi resource.
    :param context: Konteks Function Compute.
    :param resource_id: ID resource.
    :param resource_type: Jenis resource.
    :param region_id: ID wilayah tempat resource berada.
    :return: Detail resource.
    """
    # Peran layanan untuk Function Compute (FC) harus memiliki izin AliyunConfigFullAccess.
    creds = context.credentials
    config = open_api_models.Config(
        access_key_id=creds.access_key_id,
        access_key_secret=creds.access_key_secret,
        security_token=creds.security_token,
        endpoint='config.cn-shanghai.aliyuncs.com'
    )
    client = OpenApiClient(config)
    params = open_api_models.Params(
        style='RPC',  # Gaya API
        version='2020-09-07',  # Nomor versi API
        action='GetDiscoveredResource',  # Nama API
        method='POST',  # Metode permintaan
        pathname='/',  # Jalur API. Jalur default untuk API RPC adalah "/".
        protocol='HTTPS',  # Protokol API.
        auth_type='AK',
        req_body_type='json',  # Format badan permintaan.
        body_type='json'  # Format badan respons.
    )
    query = {'ResourceId': resource_id, 'ResourceType': resource_type, 'Region': region_id}
    # Buat objek permintaan API.
    request = open_api_models.OpenApiRequest(
        query=OpenApiUtilClient.query(query),
    )
    runtime = util_models.RuntimeOptions()
    try:
        response = client.call_api(params, request, runtime)
        return response
    except Exception as e:
        logger.error('Kesalahan GetDiscoveredResource: %s' % e)

EOF
  filename = "${path.module}/python/index.py"
}

resource "local_file" "requirements_txt" {
  content  = <<EOF
  alibabacloud-tea-openapi
  jmespath>= 0.10.0
  EOF
  filename = "${path.module}/python/requests/requirements.txt"
}
locals {
  code_dir       = "${path.module}/python/"
  archive_output = "${path.module}/code.zip"
  base64_output  = "${path.module}/code_base64.txt"
}

data "archive_file" "code_package" {
  type        = "zip"
  source_dir  = local.code_dir
  output_path = local.archive_output

  depends_on = [
    local_file.python_script,
    local_file.requirements_txt,
  ]
}

resource "null_resource" "upload_code" {
  provisioner "local-exec" {
    command = <<EOT
    base64 -w 0 ${local.archive_output} > ${local.base64_output}
    EOT

    interpreter = ["sh", "-c"]
  }

  depends_on = [data.archive_file.code_package]
}

data "local_file" "base64_encoded_code" {
  filename   = local.base64_output
  depends_on = [null_resource.upload_code]
}
resource "alicloud_fcv3_function" "fc_function" {
  runtime       = "python3.10"
  handler       = "index.handler"
  function_name = "HHM-FC-TEST"
  role          = alicloud_ram_role.role.arn

  code {
    zip_file = data.local_file.base64_encoded_code.content
  }
  lifecycle {
    ignore_changes = [
      code
    ]
  }

  # Secara eksplisit atur log_config menjadi kosong.
  log_config {}

  depends_on = [data.local_file.base64_encoded_code]
}

resource "alicloud_config_rule" "default" {
  rule_name    = "SPM0014-sg-disallow-risky-ports-for-all-ips"
  description  = "Melarang security group membuka port rentan 22 dan 3389 ke seluruh rentang IP."
  source_owner = "ALIYUN"
  # (Wajib, ForceNew) Menentukan apakah aturan dimiliki dan dikelola oleh Anda atau Alibaba Cloud. Nilai yang valid: CUSTOM_FC: Aturan adalah aturan kustom milik Anda. ● ALIYUN: Aturan adalah aturan terkelola milik Alibaba Cloud.
  source_identifier = "sg-risky-ports-check"
  # Pengidentifikasi aturan. Untuk aturan terkelola, nilainya adalah nama aturan terkelola tersebut. Untuk aturan kustom, nilainya adalah Nama Sumber Daya Alibaba Cloud (ARN) dari aturan kustom tersebut. (Wajib, ForceNew)
  resource_types_scope = ["ACS::ECS::SecurityGroup"]
  # ID resource yang dikecualikan dari cakupan pemantauan. Pisahkan beberapa ID dengan koma (,). Parameter ini hanya berlaku untuk aturan yang dibuat berdasarkan aturan terkelola. Untuk aturan kustom, parameter ini kosong.
  config_rule_trigger_types = "ConfigurationItemChangeNotification" # Aturan dipicu saat konfigurasi berubah.
  # Nilai yang valid: One_Hour, Three_Hours, Six_Hours, Twelve_Hours, dan TwentyFour_Hours.
  risk_level = 1 #    ● 1: Kritis ● 2: Peringatan ● 3: Informasi

  input_parameters = {
    "ports" : "22,3389"
  }
}

resource "alicloud_config_remediation" "default" {
  config_rule_id          = alicloud_config_rule.default.id
  remediation_template_id = alicloud_fcv3_function.fc_function.function_arn
  remediation_source_type = "CUSTOM"
  invoke_type             = "AUTO_EXECUTION"
  params                  = "{}"
  remediation_type        = "FC"
}

resource "random_integer" "default" {
  min = 10000
  max = 99999
}

resource "alicloud_ram_role" "role" {
  name        = "tf-example-role-${random_integer.default.result}"
  document    = <<EOF
   {
    "Statement": [
       {
        "Action": "sts:AssumeRole",
        "Effect": "Allow",
        "Principal": {
          "Service": [
            "fc.aliyuncs.com"
          ]
        }
      }
    ],
    "Version": "1"
  }
  EOF
  description = "Peran ram ECS."
  force       = true
}
resource "alicloud_ram_policy" "policy" {
  policy_name     = "tf-example-ram-policy-${random_integer.default.result}"
  policy_document = <<EOF
   {
    "Statement": [
       {
        "Action": [
          "config:GetDiscoveredResource",
          "ecs:RevokeSecurityGroup"
        ],
        "Effect":  "Allow",
        "Resource": ["*"]
      }
    ],
    "Version": "1"
  }
  EOF
  description     = "Ini adalah uji coba kebijakan."
  force           = true
}

resource "alicloud_ram_role_policy_attachment" "attach" {
  policy_name = alicloud_ram_policy.policy.policy_name
  policy_type = "Custom"
  role_name   = alicloud_ram_role.role.name
}
