Elasticsearch:Mem0 + Elasticsearch: Building an AI memory system

Step 1: Prepare Elasticsearch

1. Follow the Quick start guide to create an instance and set a login password.

2. Configure the Kibana public access whitelist:

   • Go to the Basic Information page of the target instance. In the left-side navigation pane, click Configuration and Management > > Data Visualization. In the Kibana section, click Modify Configuration.

   • Configure the Public IP Address Whitelist: The whitelist defaults to 127.0.0.1, which denies access from all IPv4 addresses. To access Kibana, add your device's public IP address to the whitelist. For more information, see Connect to a cluster through Kibana.

3. Return to the Kibana section and click Access over Internet. On the Kibana login page, enter your username and password. After a successful login, use Kibana Dev Tools to create an index named mem0:

   PUT /mem0
   {
     "settings": {
       "number_of_shards": 1,
       "number_of_replicas": 1
     }
   }

Step 2: Deploy the Mem0 server

1. Install Mem0 and Flask:

   pip install mem0ai flask

   For more installation methods, see the Mem0 README.

2. Create the Mem0 server directory:

   mkdir -p /opt/mem0-server
   cd /opt/mem0-server

3. Create a server.py file with the following content, replacing the placeholders with your actual values:

   • $API_KEY: Your Model Studio API key

   • $ELASTICSEARCH_HOST, $ELASTICSEARCH_PORT: The endpoint and port of your Elasticsearch instance

   • $ELASTICSEARCH_USER, $ELASTICSEARCH_PASSWORD: The username and password for your Elasticsearch instance

     # server.py - Run this as a standalone service
     from mem0 import Memory
     from flask import Flask, request, jsonify

     app = Flask(__name__)

     # Configure Mem0 here
     config = {
         "llm": {
             "provider": "openai",
             "config": {
                 "model": "qwen-plus",
                 "api_key": "$API_KEY",
                 "openai_base_url": "https://dashscope.aliyuncs.com/compatible-mode/v1",
             }
         },
         "embedder": {
             "provider": "openai",
             "config": {
                 "model": "text-embedding-v4",
                 "api_key": "$API_KEY",
                 "openai_base_url": "https://dashscope.aliyuncs.com/compatible-mode/v1",
             }
         },
         "vector_store": {
             "provider": "elasticsearch",
             "config": {
                 "host": "$ELASTICSEARCH_HOST",     # The host of your Elasticsearch instance
                 "port": "$ELASTICSEARCH_PORT",     # The port of your Elasticsearch instance
                 "user": "$ELASTICSEARCH_USER",     # The username for your Elasticsearch instance
                 "password": "$ELASTICSEARCH_PASSWORD",  # The password for your Elasticsearch instance
                 "collection_name": "mem0",         # The name of the index created in Step 1
             }
         },
     }

     memory = Memory.from_config(config)

     @app.route('/v1/memories', methods=['POST'])
     def add_memory():
         data = request.json
         result = memory.add(
             messages=data['messages'],
             user_id=data['user_id']
         )
         return jsonify(result)

     @app.route('/v2/memories/search', methods=['POST'])
     def search_memories():
         data = request.json
         result = memory.search(
             query=data['query'],
             user_id=data['user_id']
         )
         return jsonify(result)

     @app.route('/v1/memories', methods=['DELETE'])
     def delete_memories():
         user_id = request.args.get('user_id')
         memory.delete_all(user_id=user_id)
         return jsonify({"status": "success"})

     if __name__ == '__main__':
         app.run(host='0.0.0.0', port=8420)

4. Start the Mem0 server:

   python server.py

Step 3: Configure OpenClaw

1. Deploy OpenClaw on an ECS instance. You can choose one of the following methods:

   • Method 1 (One-click deployment with Compute Nest): Deploy OpenClaw on an ECS instance

   • Method 2 (One-click installation with Workbench):

     1. Log on to the ECS console and select the target instance.

     2. Click Remote Connection > Log On Now.

     3. In the Workbench terminal toolbar, click One-click Management for OpenClaw.

     4. Select Install OpenClaw and confirm the action.

2. Log on to the ECS instance and create the Skill directory:

   mkdir -p ~/.openclaw/workspace/skills/agentic-memory-es
   cd ~/.openclaw/workspace/skills/agentic-memory-es

3. Create these three files in this directory:

   agentic-memory-es/
   ├── manifest.json    # Metadata and API definition
   ├── handler.py       # Core processing logic
   └── SKILL.md         # Instruction document

   manifest.json:

   {
     "name": "agentic memory",
     "id": "agentic-memory-es",
     "version": "1.0.0",
     "description_for_model": "A memory platform based on Mem0 + Elasticsearch. Supports adding (add), searching (search), deleting by run ID (delete_by_run_id), and deleting by user ID (delete_by_user_id).",
     "description_for_human": "An agent memory platform powered by Alibaba Cloud Elasticsearch.",
     "auth": {
       "type": "token",
       "token_header": "Authorization",
       "token_prefix": "Token"
     },
     "api": {
       "type": "python",
       "main_file": "handler.py",
       "functions": [
         {
           "name": "add",
           "description": "Extracts facts, user preferences, or habits from a session and persists them.",
           "parameters": {
             "type": "object",
             "properties": {
               "user_id": { "type": "string", "description": "user ID" },
               "context": { "type": "string", "description": "Session content" }
             },
             "required": ["user_id", "context"]
           }
         },
         {
           "name": "search",
           "description": "Retrieves user-level historical memories (cross-session).",
           "parameters": {
             "type": "object",
             "properties": {
               "user_id": { "type": "string", "description": "user ID" },
               "query": { "type": "string", "description": "Search query" }
             },
             "required": ["user_id", "query"]
           }
         },
         {
           "name": "delete_by_run_id",
           "description": "Deletes the historical memory associated with a run ID.",
           "parameters": {
             "type": "object",
             "properties": {
               "run_id": { "type": "string", "description": "run ID" }
             },
             "required": ["run_id"]
           }
         },
         {
           "name": "delete_by_user_id",
           "description": "Deletes the historical memory associated with a user ID.",
           "parameters": {
             "type": "object",
             "properties": {
               "user_id": { "type": "string", "description": "user ID" }
             },
             "required": ["user_id"]
           }
         }
       ]
     }
   }

   handler.py:

   Replace $Mem0_HOST with the endpoint of the Mem0 server you deployed in Step 2:

   • If the Mem0 server and OpenClaw are on the same ECS instance, use http://127.0.0.1:8420.

   • If they are on different machines, use the internal or public IP address of the Mem0 server.

   import json
   import subprocess

   HOST = "$Mem0_HOST"

   def _run_safe_curl(url, payload, method='POST'):
       if payload is not None:
           input_data = json.dumps(payload, ensure_ascii=False)
       else:
           input_data = ""

       cmd = [
           "curl", "-s", "-X", method, url,
           "-H", "Content-Type: application/json",
           "--data-binary", "@-",
           "--max-time", "15",
           "--no-buffer"
       ]

       try:
           input_data = json.dumps(payload)

           result = subprocess.run(
               cmd, input=input_data, capture_output=True,
               text=True, check=True, encoding='utf-8'
           )

           output = result.stdout.strip()
           if not output:
               return {"status": "success"}
           return json.loads(output)

       except subprocess.CalledProcessError as e:
           return {"error": f"Curl command failed: {e.stderr}"}
       except Exception as e:
           return {"error": str(e)}

   def add(user_id, context):
       url = f"{HOST}/v1/memories"
       payload = {
           "messages": [
               {"role": "user", "content": context}
           ],
           "user_id": str(user_id)
       }
       return _run_safe_curl(url, payload, method='POST')

   def search(user_id, query):
       url = f"{HOST}/v2/memories/search"
       payload = {
           "query": query,
           "user_id": str(user_id)
       }
       return _run_safe_curl(url, payload, method='POST')

   def delete_by_run_id(run_id):
       url = f"{HOST}/v1/memories?run_id={run_id}"
       return _run_safe_curl(url, payload=None, method='DELETE')

   def delete_by_user_id(user_id):
       url = f"{HOST}/v1/memories?user_id={user_id}"
       return _run_safe_curl(url, payload=None, method='DELETE')

   SKILL.md:

   ---
   name: agentic memory
   description: A memory platform based on Mem0 + Elasticsearch.
   allowed-tools:
     - add
     - search
     - delete_by_run_id
     - delete_by_user_id
   metadata:
     category: memory
     provider: elasticsearch
   ---

   # Instructions
   You now have access to a memory store powered by Elasticsearch. This skill integrates the Mem0 + Elasticsearch service to provide OpenClaw with long-term memory, replacing the native .md file storage. It enables precise extraction and millisecond-level retrieval of user preferences, facts, and event relationships, supporting cross-session knowledge persistence. Follow these principles:
   1. Proactive memorization: Capture core facts (identity, skills) or explicit preferences (habits, restrictions).
      - When the user mentions, "I am developing an agent assistant," call add. - When the user expresses a preference like, "I like to plan before I start," or "I don't like to be disturbed while working," call add. 2. Contextual retrieval: When starting a new task or reviewing history, call search to retrieve memories and ensure a coherent conversation. 3. Forgetting a memory: If the user abandons a decision (e.g., "I don't want to worry about this anymore"), call delete_by_run_id to delete the memory associated with that run ID. 4. Clearing memories: If the user decides to clear all memories, call delete_by_user_id to delete all memories for that user ID. # Tools ## Memory Management (Mem0 + Elasticsearch) This toolset provides memory capabilities based on Mem0 + Elasticsearch, enabling the agent to persist and retrieve memories across different sessions. ### 1. add - Description: Extracts facts, user preferences, or habits from a session and persists them. - Required parameters: - user_id (string): The unique identifier for the user. - context (string): The content of the session. - Returns: An object containing the operation status or the ID of the newly stored record. ### 2. search - Description: Retrieves user-level historical memories (cross-session). - Required parameters: - user_id (string): The unique identifier for the user. - query (string): The search query. - Returns: An object containing results sorted by relevance. ### 3. delete_by_run_id - Description: Deletes the historical memory associated with a run ID. - Required parameters: - run_id (string): An identifier for isolating temporary sessions (such as support tickets) that need to be reset independently. - Returns: An operation confirmation message. ### 4. delete_by_user_id - Description: Deletes the historical memory associated with a user ID. - Required parameters: - user_id (string): The unique identifier for the user. - Returns: An operation confirmation message. # Output Format 1. Natural integration: Do not mention terms like "searching memory." Directly embed facts as known context in your replies (e.g., "Based on the fact that you're learning Rust, I suggest..."). 2. Context awareness: Prioritize using retrieved facts to make personalized decisions and provide customized technical guidance. 3. Graceful handling: If no relevant memory is found, generate a high-quality response directly. Do not mention "no memory found" or "search failed." 4. Action feedback: After a successful add call, confirm it naturally at the end of the reply (e.g., "I've noted your preference"), avoiding robotic system prompts. # Examples ### Scenario 1: Add a memory User input: "I plan to scale out my Elasticsearch service next month." Action: add(user_id="user_01", context="Plans to scale out Elasticsearch next month") ### Scenario 2: Search for a memory User input: "Check my previous scale-out plan." Action: search(user_id="user_01", query="scale-out plan") ### Scenario 3: Forget a memory (Delete by run ID) User input: "Forget the previous scale-out plan; we're not going to do it anymore." Action: delete_by_run_id(run_id="run_01") ### Scenario 4: Clear user memories (Delete by user ID) User input: "Clear all my memories." Action: delete_by_user_id(user_id="user_01") # Tags Memory-as-a-Service Elasticsearch Mem0 # Limitations - Complexity limit: Avoid saving extremely long paragraphs as a single fact. Split them into shorter, semantically defined statements for better retrieval accuracy.

4. Refresh the Skills or restart the OpenClaw Gateway.

Step 4: Verify the results

After deploying the Mem0 server, verify its functionality as follows:
