ID Verification:Custom UI configuration for the iOS SDK

Interface definition

The iOS SDK provides the setCustomUI interface to customize UI colors and icons. You can call this method and pass the corresponding parameters to customize the UI.

/**
 * Set custom UI colors and icons
 *
 * Set custom UI
 * @param configuration - Input JSON string
 * @param completeBlock - Callback for the configuration results
*/
- (void)setCustomUI:(nonnull NSString *)configuration
           complete:(void(^_Nullable)(BOOL success, NSError * _Nullable error))completeBlock;

Request parameters

Sample code

[[AliyunIdentityPlatform sharedInstance] setCustomUI:@"" complete:^(BOOL success, NSError * _Nullable error) {
     	NSLog(@"%@",error.localizedDescription);
}];

Full configuration example

{
  "faceConfig": {
    "exitIconBase64": "exit_icon_base64",
    "faceBGColor": "#FFFFFF",
    "faceTitleColor": "#000000",
    "faceTipColor": "#000000",
    "opFailedTitleColor": "#000000",
    "opFailedTipColor": "#000000",
    "opFailedConfirmColor": "#4FA3EC",
    "faceProgressEndColor": "#E3824C",
    "exitAlertTitleColor": "#000000",
    "exitAlertMessageColor": "#000000",
    "exitAlertCancelColor": "#4FA3EC",
    "exitAlertConfirmationColor": "#4FA3EC",
    "timeoutAlertTitleColor": "#000000",
    "timeoutAlertMessageColor": "#000000",
    "timeoutAlertConfirmationColor": "#4FA3EC",
    "tooManyRetriesAlertTitleColor": "#000000",
    "tooManyRetriesAlertMessageColor": "#000000",
    "tooManyRetriesAlertConfirmColor": "#4FA3EC",
    "interruptedAlertTitleColor": "#000000",
    "interruptedAlertMessageColor": "#000000",
    "interruptedAlertConfirmColor": "#4FA3EC",
    "permissionFailedAlertTitleColor": "#000000",
    "permissionFailedAlertMessageColor": "#000000",
    "permissionFailedAlertConfirmColor": "#4FA3EC",
    "verifyNetworkErrorAlertTitleColor": "#000000",
    "verifyNetworkErrorAlertMessageColor": "#000000",
    "verifyNetworkErrorAlertConfirmColor": "#4FA3EC",
    "verifyNetworkErrorAlertCancelColor": "#4FA3EC",
    "verifyLoadingColor": "#585858"
  },
  "ocrConfig": {
    "exitIconBase64": "exit_icon_base64",
    "albumBase64": "album_base64",
    "takePhotoBase64": "take_photo_base64",
    "submitBase64": "submit_base64",
    "ocrResultExitIconBase64": "ocr_result_exit_icon_base64",
    "ocrResultTipIconBase64": "ocr_result_tip_icon_base64",
    "ocrTitleColor": "#FFFFFF",
    "ocrBorderColor": "#E3824C",
    "ocrSubmitTitleColor": "#FFFFFF",
    "ocrLoadingColor": "#FFFFFF",
    "failedAlertTitleColor": "#000000",
    "failedAlertMessageColor": "#000000",
    "failedAlertCancelColor": "#4FA3EC",
    "failedAlertConfirmationColor": "#4FA3EC",
    "timeoutAlertTitleColor": "#000000",
    "timeoutAlertMessageColor": "#000000",
    "timeoutAlertConfirmationColor": "#4FA3EC",
    "exitAlertTitleColor": "#000000",
    "exitAlertCancelColor": "#4FA3EC",
    "exitAlertConfirmationColor": "#4FA3EC",
    "ocrResultTitleColor": "#000000",
    "ocrResultTipBGColor": "#DFDFDF",
    "ocrResultTipColor": "#000000",
    "ocrResultInfoTitleColor": "#000000",
    "ocrResultInfoContentColor": "#F6F6F6",
    "ocrResultInfoBorderColor": "#E3824C",
    "ocrResultTipTitleColor": "#D59F9E",
    "ocrResultErrorTipBGColor": "#F6DAD5",
    "ocrResultConfirmBtnDisabledBGColor": "#DADADA",
    "ocrResultConfirmBtnDisabledTitleColor": "#FFFFFF",
    "ocrResultConfirmBtnEnabledBGColor": "",
    "ocrResultConfirmBtnEnabledTitleColor": "#FFFFFF",
    "ocrResultExitAlertTitleColor": "#000000",
    "ocrResultExitAlertCancelColor": "#000000",
    "ocrResultExitAlertConfirmationColor": "#4FA3EC",
    "restrictionsAlertTitleColor": "#000000",
    "restrictionsAlertMessageColor": "#000000",
    "restrictionsAlertConfirmationColor": "#4FA3EC",
    "permissionFailedAlertTitleColor": "#000000",
    "permissionFailedAlertMessageColor": "#000000",
    "permissionFailedAlertConfirmColor": "#4FA3EC",
    "ocrNetworkErrorAlertTitleColor": "#000000",
    "ocrNetworkErrorAlertMessageColor": "#000000",
    "ocrNetworkErrorAlertCancelColor": "#4FA3EC",
    "ocrNetworkErrorAlertConfirmColor": "#4FA3EC",
    "docErrorAlertTitleColor": "#000000",
    "docErrorAlertMessageColor": "#000000",
    "docErrorAlertCancelColor": "#4FA3EC",
    "docErrorAlertConfirmColor": "#4FA3EC",
    "ocrResultNetworkErrorAlertTitleColor": "#000000",
    "ocrResultNetworkErrorAlertMessageColor": "#000000",
    "ocrResultNetworkErrorAlertConfirmColor": "#4FA3EC",
    "ocrResultInfoErrorAlertMessageColor": "#000000",
    "ocrResultInfoErrorAlertConfirmColor": "#4FA3EC",
    "ocrResultLoadingColor": "#FFFFFF"
  }
}
