Android SDK UI自定义配置说明 - ID Verification

ID Verification Android SDK提供自定义UI颜色、icon图标的接口，开发者可以通过编写自定义UI配置，以文件或JSON数据格式通过传入setCustomUIConfig接口实现UI的自定义效果。本文为您介绍UI自定义接口说明以及相关的代码示例。

说明

部分自定义配置可能需要依赖SDK升级，建议您在使用之前将SDK升级至最新版本。如用户界面自定义设置与验证接口的扩展参数存在冲突，优先使用用户界面自定义设置。请确保 UI 自定义设置优先于任何验证接口参数，以提供一致且直观的用户体验。

接口说明

接口定义

Android SDK中提供了自定义UI颜色和icon图标的接口：setCustomUIConfig。您可以通过调用此方法并传入对应参数来实现自定义UI的效果。

    /**
     * 设置自定义UI颜色和icon图标
     *
     * @return 配置文件检测出的异常信息。
     * @description 此接口用于设置自定义UI。
     * @paramType paramType 参数类型{@link IDTFacade} ，可传范围
     * {@link IDTFacade.EXT_PARAMS_CONFIG_JSON} | {@link IDTFacade.EXT_PARAMS_CONFIG_ASSETS_NAME}）。
     *
     * @params {@link String} params 参数值，与paramType相对应的值。
     */
    public String setCustomUIConfig(@IDTFacade int paramType, String param) {
     // ...
    }

入参说明

名称

类型

说明

paramType

int

配置自定义入参的类型，可选值：

IDTFacade.EXT_PARAMS_CONFIG_ASSETS_NAME：App assets文件类型，param传入assets文件名称。
IDTFacade.EXT_PARAMS_CONFIG_JSON：JSON字符串，params传入JSON格式数据。

param

String

根据paramType取值传入相应数据。

返回值

String类型，当SDK对param内容解析遇到错误或出现异常信息时会通过提示信息的方式返回。当配置参数无效时，请重点关注返回值信息。

示例代码

//传入assets文件名
String fileName = "DTFCustomUIConfig.json";
int paramType = IDTFacade.EXT_PARAMS_CONFIG_ASSETS_NAME;
String customUIErrMsg =  IdentityPlatform.getInstance().setCustomUIConfig(paramType, fileName);

//传入JSON字符串
String jsonConfig = "<JSON格式的自定义UI配置>";
int paramType = IDTFacade.EXT_PARAMS_CONFIG_JSON;
String customUIErrMsg =  IdentityPlatform.getInstance().setCustomUIConfig(paramType, jsonConfig);

自定义UI配置

自定义UI目前允许用户自定义认证页面的字体颜色和部分Icon。

完整配置示例

{
  "faceConfig": {
    "faceBGColor": "#A8D8B4",
    "exitIconBase64": "exit_icon_base64",
    "faceTitleColor": "#3E5E7E",
    "faceTipColor": "#F0E68C",
    "interruptedAlertTitleColor": "#FF6347",
    "interruptedAlertMessageColor": "#4682B4",
    "interruptedAlertConfirmColor": "#DDA0DD",
    "permissionFailedAlertTitleColor": "#6A5ACD",
    "permissionFailedAlertMessageColor": "#8A2BE2",
    "permissionFailedAlertConfirmColor": "#5F9EA0",
    "tooManyRetriesAlertTitleColor": "#DC143C",
    "tooManyRetriesAlertMessageColor": "#00FFFF",
    "tooManyRetriesAlertConfirmColor": "#B8860B",
    "faceProgressStartColor": "#006400",
    "faceProgressEndColor": "#BDB76B",
    "exitAlertTitleColor": "#8B008B",
    "exitAlertMessageColor": "#556B2F",
    "exitAlertCancelColor": "#FF8C00",
    "exitAlertConfirmationColor": "#9932CC",
    "timeoutAlertTitleColor": "#E9967A",
    "timeoutAlertMessageColor": "#8FBC8F",
    "timeoutAlertConfirmationColor": "#483D8B",
    "verifyLoadingColor": "#2F4F4F",
    "verifyNetworkErrorAlertTitleColor": "#00CED1",
    "verifyNetworkErrorAlertMessageColor": "#9400D3",
    "verifyNetworkErrorAlertCancelColor": "#FF1493",
    "verifyNetworkErrorAlertConfirmColor": "#00BFFF"
  },
  "ocrConfig": {
    "exitIconBase64": "exit_icon_base64",
    "ocrTitleColor": "#696969",
    "ocrBorderColor": "#1E90FF",
    "albumBase64": "album_base64",
    "takePhotoBase64": "take_photo_base64",
    "submitBase64": "submit_base64",
    "ocrSubmitTitleColor": "#B22222",
    "ocrLoadingColor": "#FFFAF0",
    "failedAlertTitleColor": "#228B22",
    "failedAlertMessageColor": "#FF00FF",
    "failedAlertCancelColor": "#DCDCDC",
    "failedAlertConfirmationColor": "#F8F8FF",
    "ocrNetworkErrorAlertTitleColor": "#FFD700",
    "ocrNetworkErrorAlertMessageColor": "#DAA520",
    "ocrNetworkErrorAlertCancelColor": "#808080",
    "ocrNetworkErrorAlertConfirmColor": "#008000",
    "permissionFailedAlertTitleColor": "#ADFF2F",
    "permissionFailedAlertMessageColor": "#F0FFF0",
    "permissionFailedAlertConfirmColor": "#FF69B4",
    "docErrorAlertTitleColor": "#CD5C5C",
    "docErrorAlertMessageColor": "#4B0082",
    "docErrorAlertCancelColor": "#FFFFF0",
    "docErrorAlertConfirmColor": "#F0E68C",
    "restrictionsAlertTitleColor": "#E6E6FA",
    "restrictionsAlertMessageColor": "#FFF0F5",
    "restrictionsAlertConfirmationColor": "#7CFC00",
    "timeoutAlertTitleColor": "#FFFACD",
    "timeoutAlertMessageColor": "#ADD8E6",
    "timeoutAlertConfirmationColor": "#F08080",
    "exitAlertTitleColor": "#E0FFFF",
    "exitAlertCancelColor": "#FAFAD2",
    "exitAlertConfirmationColor": "#D3D3D3",
    "ocrMessageFailAlertTitleColor": "#90EE90",
    "ocrMessageFailAlertCancelColor": "#FFB6C1",
    "ocrMessageFailAlertConfirmColor": "#FFA07A",
    "ocrResultExitIconBase64": "ocr_result_exit_icon_base64",
    "ocrResultTitleColor": "#20B2AA",
    "ocrResultTipBGColor": "#87CEFA",
    "ocrResultTipColor": "#778899",
    "ocrResultInfoTitleColor": "#B0C4DE",
    "ocrResultInfoContentColor": "#FFFFE0",
    "ocrResultConfirmBtnEnabledBGColor": "#00FF00",
    "ocrResultConfirmBtnEnabledTitleColor": "#32CD32",
    "ocrResultTipTitleColor": "#FAF0E6",
    "ocrResultTipIconBase64": "ocr_result_tip_icon_base64",
    "ocrResultErrorTipBGColor": "#FF00FF",
    "ocrResultInfoBorderColor": "#800000",
    "ocrResultConfirmBtnDisabledBGColor": "#66CDAA",
    "ocrResultConfirmBtnDisabledTitleColor": "#0000CD",
    "ocrResultExitAlertTitleColor": "#BA55D3",
    "ocrResultExitAlertCancelColor": "#9370DB",
    "ocrResultExitAlertConfirmationColor": "#3CB371",
    "ocrResultInfoEmptyAlertTitleColor": "#7B68EE",
    "ocrResultInfoEmptyAlertConfirmColor": "#00FA9A",
    "ocrResultNetworkErrorAlertTitleColor": "#48D1CC",
    "ocrResultNetworkErrorAlertMessageColor": "#C71585",
    "ocrResultNetworkErrorAlertConfirmColor": "#191970",
    "ocrResultNetworkErrorAlertCancelColor": "#F5FFFA",
    "ocrResultInfoErrorAlertMessageColor": "#FFE4E1",
    "ocrResultInfoErrorAlertConfirmColor": "#FFE4B5",
    "unFloodLightBase64": "un_flood_light_base64",
    "floodLightBase64": "flood_light_base64",
    "autoScanBase64": "auto_scan_base64",
    "takeShootBase64": "take_shoot_base64",
    "ocrTakePhotoLabelColor": "#FFDEAD",
    "ocrAlbumLabelColor": "#000080",
    "ocrGuideExitIconBase64": "ocr_guide_exit_icon_base64",
    "ocrGuideTitleColor": "#FDF5E6",
    "ocrGuideContentColor": "#808000",
    "ocrGuideStartBtnBGColor": "#6B8E23",
    "ocrGuideStartBtnTextColor": "#FFA500",
    "ocrGuideIndicatorSelectedColor": "#FF4500",
    "ocrGuideIndicatorUnSelectedColor": "#DA70D6",
    "nfcInputExitIconBase64": "nfc_input_exit_icon_base64",
    "nfcInputTitleColor": "#EEE8AA",
    "nfcInputPassportLabelColor": "#98FB98",
    "nfcInputBirthdayLabelColor": "#AFEEEE",
    "nfcInputValidityLabelColor": "#DB7093",
    "nfcInputPassportEditColor": "#FFEFD5",
    "nfcInputBirthdayEditColor": "#FFDAB9",
    "nfcInputValidityEditColor": "#CD853F",
    "nfcInputPassportEditHintColor": "#FFC0CB",
    "nfcInputBirthdayEditHintColor": "#DDA0DD",
    "nfcInputValidityEditHintColor": "#B0E0E6",
    "nfcInputNextBtnBGSelectColor": "#800080",
    "nfcInputNextBtnTextSelectColor": "#663399",
    "nfcInputNextBtnBGUnSelectColor": "#FF0000",
    "nfcInputNextBtnTextUnSelectColor": "#BC8F8F",
    "nfcInputBackAlertTitleColor": "#4169E1",
    "nfcInputBackAlertCancelColor": "#8B4513",
    "nfcInputBackAlertConfirmColor": "#FA8072",
    "nfcInputCheckAlertTitleColor": "#F4A460",
    "nfcInputCheckAlertMessageColor": "#2E8B57",
    "nfcInputCheckAlertConfirmColor": "#A0522D",
    "nfcExitIconBase64": "nfc_exit_icon_base64",
    "nfcTitleColor": "#C0C0C0",
    "nfcContentColor": "#87CEEB",
    "nfcConfirmBtnBGColor": "#6A5ACD",
    "nfcConfirmBtnTextColor": "#708090",
    "nfcReadBackAlertTitleColor": "#00FF7F",
    "nfcReadBackAlertConfirmColor": "#4682B4",
    "nfcReadBackAlertCancelColor": "#D2B48C",
    "nfcSettingAlertTitleColor": "#D2691E",
    "nfcSettingAlertMessageColor": "#9ACD32",
    "nfcSettingAlertConfirmColor": "#FF7F50",
    "nfcSettingAlertCancelColor": "#6495ED",
    "nfcReadStatusExitBase64": "nfc_read_status_exit_base64",
    "nfcReadStatusTextColor": "#DC143C"
  }
}

字段配置效果

faceModule

faceBGColor

exitIconBase64

faceTitleColor

faceTipColor

interruptedAlertTitleColor

interruptedAlertMessageColor

interruptedAlertConfirmColor

permissionFailedAlertTitleColor

permissionFailedAlertMessageColor

permissionFailedAlertConfirmColor

tooManyRetriesAlertTitleColor

tooManyRetriesAlertMessageColor

tooManyRetriesAlertConfirmColor

faceProgressStartColor

faceProgressEndColor

exitAlertTitleColor

exitAlertMessageColor

exitAlertCancelColor

exitAlertConfirmationColor

timeoutAlertTitleColor

timeoutAlertMessageColor

timeoutAlertConfirmationColor

verifyLoadingColor

verifyNetworkErrorAlertTitleColor

verifyNetworkErrorAlertMessageColor

verifyNetworkErrorAlertCancelColor

verifyNetworkErrorAlertConfirmColor

ocrModule

exitIconBase64

ocrTitleColor

ocrBorderColor

albumBase64

takePhotoBase64

submitBase64

ocrSubmitTitleColor

ocrLoadingColor

failedAlertTitleColor

failedAlertMessageColor

failedAlertCancelColor

failedAlertConfirmationColor

ocrNetworkErrorAlertTitleColor

ocrNetworkErrorAlertMessageColor

ocrNetworkErrorAlertCancelColor

ocrNetworkErrorAlertConfirmColor

permissionFailedAlertTitleColor

permissionFailedAlertMessageColor

permissionFailedAlertConfirmColor

docErrorAlertTitleColor

docErrorAlertMessageColor

docErrorAlertCancelColor

docErrorAlertConfirmColor

restrictionsAlertTitleColor

restrictionsAlertMessageColor

restrictionsAlertConfirmationColor

timeoutAlertTitleColor

timeoutAlertMessageColor

timeoutAlertConfirmationColor

exitAlertTitleColor

exitAlertCancelColor

exitAlertConfirmationColor

ocrMessageFailAlertTitleColor

ocrMessageFailAlertCancelColor

ocrMessageFailAlertConfirmColor

ocrResultExitIconBase64

ocrResultTitleColor

ocrResultTipBGColor

ocrResultTipColor

ocrResultInfoTitleColor

ocrResultInfoContentColor

ocrResultConfirmBtnEnabledBGColor

ocrResultConfirmBtnEnabledTitleColo

ocrResultTipTitleColor

ocrResultTipIconBase64

ocrResultErrorTipBGColor

ocrResultInfoborderColor

ocrResultConfirmBtnDisabledBGColor

ocrResultConfirmBtnDisabledTitleColor

ocrResultExitAlertTitleColor

ocrResultExitAlertCancelColor

ocrResultExitAlertConfirmationColor

ocrResultInfoEmptyAlertTitleColor

ocrResultInfoEmptyAlertConfirmColor

ocrResultNetworkErrorAlertTitleColor

ocrResultNetworkErrorAlertMessageColor

ocrResultNetworkErrorAlertConfirmColor

ocrResultNetworkErrorAlertCancleColor

ocrResultInfoErrorAlertMessageColor

ocrResultInfoErrorAlertConfirmColor

unFloodLightBase64

floodLightBase64

autoScanBase64

takeShootBase64

ocrTakePhotoLabelColor

ocrAlbumLabelColor

ocrGuideExitIconBase64

ocrGuideTitleColor

ocrGuideContentColor

ocrGuideStartBtnBGColor

ocrGuideStartBtnTextColor

ocrGuideIndicatorSelectedColor

ocrGuideIndicatorUnSelectedColor

nfcInputExitIconBase64

nfcInputTitleColor

nfcInputPassportLabelColor

nfcInputBirthdayLabelColor

nfcInputValidityLabelColor

nfcInputPassportEditColor

nfcInputBirthdayEditColor

nfcInputValidityEditColor

nfcInputPassportEditHintColor

nfcInputBirthdayEditHintColor

nfcInputValidityEditHintColor

nfcInputNextBtnBGSelectColor

nfcInputNextBtnTextSelectColor

nfcInputNextBtnBGUnSelectColor

nfcInputNextBtnTextUnSelectColor

nfcInputBackAlertTitleColor

nfcInputBackAlertCancelColor

nfcInputBackAlertConfirmColor

nfcInputCheckAlertTitleColor

nfcInputCheckAlertMessageColor

nfcInputCheckAlertConfirmColor

nfcExitIconBase64

nfcTitleColor

nfcContentColor

nfcConfirmBtnBGColor

nfcConfirmBtnTextColor

nfcReadBackAlertTitleColor

nfcReadBackAlertConfirmColor

nfcReadBackAlertCancelColor

nfcSettingAlertTitleColor

nfcSettingAlertMessageColor

nfcSettingAlertConfirmColor

nfcSettingAlertCancelColor

nfcReadStatusExitBase64

nfcReadStatusTextColor
