Quick Tracking：分析資料

鑒權依據

API ID、API Secret。由於資料敏感，所以只在主帳號中可見，具體展示位置為：管理主控台 > 採集資訊。

URL參數

http://xxx.yyy.com/api/{service}?api_id=abcdef&api_sign=abcdef&api_ts=123456

body參數

{
    "dataSourceId": "32772108106530",
    "reportId":"rh2m151qj7bmh67uiqv46il4vfn8vckc",
    "timeUnit":"day",
    "fromDate":"2021-12-01",
    "toDate": "2021-12-23"
}

鑒權簽名

方法名 + 參數按照key進行字母排序。

/**
 * Quick Tracking後台主帳號可查看
 */
String secret = "abcdef";

/**
 * 當前要請求的服務名
 */
String service = "analysis.report.data";

/**
 * 1.擷取URL參數，如apiId=abcdef&sign=abcdef&ts=123456
 * 2.按照key排序，移除sign，結果apiId=abcdef&ts=123456
 */
String queryString = sort("api_id=abcdef&api_ts=123456");

/**
 * POST介面，body內容
 */
String bodyString = "{
    "dataSourceId": "32772108106530",
    "reportId":"rh2m151qj7bmh67uiqv46il4vfn8vckc",
    "timeUnit":"day",
    "fromDate":"2021-12-01",
    "toDate": "2021-12-23"
}";

String source = service
    + "\n"
    + queryString
    + "\n"
    + bodyString;

用API Secret對source進行加密

String sign = new HmacUtils(HmacAlgorithms.HMAC_SHA_1, secret).hmacHex(source);

sign = 1cfc10a297397e91f1e50e1f41ac24b8c45fd53d

<dependency>
  <groupId>com.squareup.okhttp3</groupId>
  <artifactId>okhttp</artifactId>
  <version>3.3.0</version>
</dependency>

package com.alibaba.umeng.base.product.advanced.controller;

import com.alibaba.fastjson.JSONObject;
import okhttp3.*;
import org.apache.commons.codec.digest.HmacAlgorithms;
import org.apache.commons.codec.digest.HmacUtils;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;

import java.io.IOException;

/**
 * @author mingpeng.spc
 * @date 2022/01/07
 */
public class OpenApiControllerTest {

    private static final MediaType APPLICATION_JSON = MediaType.parse("application/json; charset=utf-8");

    private final static Logger LOGGER = LoggerFactory.getLogger(OpenApiControllerTest.class);

    public static void main(String[] args) {

        String URL = "http://pre.aplus.emas-poc.com/api/";
        String service = "analysis.report.data";

        String apiId = "avWYU24hvdl62V8p";
        String apiSecret = "xezIgkcrtZ2yLQA4LYgBuyUo6Re2hCu8";

        /**
         * 構造URL參數
         */
        String query = new StringBuilder()
                .append("api_id=").append(apiId)
                .append("&")
                .append("api_ts=").append(System.currentTimeMillis())
                .toString();

        /**
         * 構造body參數
         */
        JSONObject body = new JSONObject();
        body.put("dataSourceId", "69412108036695");
        body.put("reportId", "7f6o7no8gks3uebieto2lmlv6o6728bj");
        body.put("timeUnit", "day");
        body.put("fromDate", "2021-12-31");
        body.put("toDate", "2022-01-06");

        String bodyString = body.toJSONString();

        /**
         * service
         * query
         * body
         */
        StringBuilder valueToDigest = new StringBuilder()
                .append(service)
                .append("\n")
                .append(query)
                .append("\n")
                .append(bodyString);

        String sign = new HmacUtils(HmacAlgorithms.HMAC_SHA_1, apiSecret).hmacHex(valueToDigest.toString());

        try {
            Response response = post(URL + service + "?" + query + "&api_sign=" + sign, bodyString);
            System.out.println(response.body().string());
        } catch (Exception e) {
            LOGGER.info("invoke post error", e);
        }
    }

    /**
     * HTTP Post
     * @param URL URL
     * @param body 請求body
     * @return
     */
    private static Response post(String URL, String body) throws IOException {

        LOGGER.info("http post start, URL = {}, body = {}", URL, body);

        RequestBody requestBody = RequestBody.create(APPLICATION_JSON, body);
        Request request = new Request.Builder()
                .URL(URL)
                .post(requestBody)
                .build();
        Response response = new OkHttpClient().newCall(request).execute();

        LOGGER.info("http post success");

        return response;
    }
}

（1）analysis.report.download：下載規則的全量資料。

請求

和report.data請求一致。

{
   "dataSourceId":"84702206076390",
   "reportId":"kpunvt6keavnim9ip7qt2ku8gpnvf5i1",
   "timeUnit":"day",
   "fromDate":"2025-02-14",
   "toDate":"2025-02-20"
}

響應

響應中有本次下載的分析AnalysisId

{
  "code": 200,
  "msg": "SUCCESS",
  "sCode": 200,
  "sMsg": "SUCCESS",
  "data": {
    "analysisId": "segmentation_adhoc_download_1740119826316",
    "taskId": 36282502216715
  },
  "traceId": "1ecbb42517401198225971041d33fc",
  "success": true
}
