The messaging feature is a basic feature provided by ApsaraMQ for RocketMQ. After you activate ApsaraMQ for RocketMQ, the messaging feature is enabled by default. This topic describes the pricing details of the messaging feature of ApsaraMQ for RocketMQ Standard Edition instances. This topic also provides billing examples.
Billing formula
ApsaraMQ for RocketMQ Standard Edition instances are billed based on the pay-as-you-go billing method. Instances of this edition are suitable for scenarios in which the number of messages is small or greatly fluctuates. You are charged only for messages that are transmitted and resources that are used. This helps maximize your resource utilization.
The messaging fees of a Standard Edition instance is calculated by using the following formula.
API call fees
Description
API call fees = (Number of API calls initiated to receive messages + Number of API calls initiated to deliver messages) × Unit price of API calls
You are charged for API calls based on the total number of API calls that are initiated to receive and deliver messages on a broker each month. Tiered pricing is used to calculate API call fees. The unit prices of API calls vary based on the region.
The following rules are used to calculate the number of API calls that are initiated to receive and deliver messages:
Each time an ApsaraMQ for RocketMQ broker receives a normal message, one API call to receive messages is counted. Each time an ApsaraMQ for RocketMQ broker delivers a normal message, one API call to deliver messages is counted, regardless of whether the message is consumed.
One API call to receive or deliver an advance-featured message is counted as five API calls to receive or deliver a normal message. For example, if an ApsaraMQ for RocketMQ broker receives one transactional message and delivers the message to a consumer twice, the number of API calls that are initiated to receive and deliver the transactional message is 15. The number of API calls is calculated by using the following formula: 1 × 5 + 2 × 5 = 15.
The maximum size of a message body is 4 MB. The system calculates the number of API calls based on a message size of 4 KB. For example, if an ApsaraMQ for RocketMQ broker delivers a message that is 16 KB in size, the number of API calls that are initiated to deliver the message is 4. The number of API calls is calculated by using the following formula: 16/4 = 4.
If you use an HTTP client to consume messages, the consumer client actively calls the consumption method to obtain messages. The frequency to call the consumption method is controlled by the consumer application.
If the ApsaraMQ for RocketMQ broker successfully returns messages, the number of API calls that are initiated to deliver the messages is calculated by using the following formula: Number of API calls initiated to deliver messages = Number of messages × Multiplier for advance-featured messages × Multiplier for message size.
If the ApsaraMQ for RocketMQ broker does not return messages, the number of API calls that are initiated to deliver the messages is counted as one.
ApsaraMQ for RocketMQ provides the following types of messages: normal messages, scheduled messages, delayed messages, transactional messages, and ordered messages. All these types of messages are advance-featured messages except for normal messages. For more information, see Message types.
Unit prices
Prices at different tiers
NoteEach Alibaba Cloud account has a total free quota of 20 million API calls for messaging each month. The prices in the following table are for API calls that exceed the free quota.
Table 3. API call fees Billing tier
Number of API calls initiated to receive and deliver messages (100 million calls per month)
Unit price by region (USD per one million calls)
UAE (Dubai), Singapore, China (Hong Kong), Japan (Tokyo), UK (London), Germany (Frankfurt), US (Virginia), US (Silicon Valley), and Australia (Sydney)
Malaysia (Kuala Lumpur), India (Mumbai), Indonesia (Jakarta), and Philippines (Manila)
Internet, China (Hangzhou), China (Shanghai), China (Shenzhen), China (Chengdu), China (Qingdao), China (Beijing), China (Zhangjiakou), and China (Hohhot)
SAU (Riyadh)
First tier
0 to 10
0.45
0.42
0.31
0.54
Second tier
10 to 50
0.41
0.38
0.28
0.492
Third tier
50 to 100
0.34
0.31
0.23
0.408
Fourth tier
100 to 500
0.3
0.27
0.20
0.36
Fifth tier
> 500
0.27
0.25
0.19
0.324
Rules for tiered pricing
The tiered pricing schedule is based on the total number of API calls that are initiated to receive and deliver messages by an Alibaba Cloud account each month.
NoteIf you use an Alibaba Cloud account to authorize another Alibaba Cloud account by using a Resource Access Management (RAM) role, the bill is charged to the authorizing Alibaba Cloud account. If you use an Alibaba Cloud account to authorize RAM users in the Alibaba Cloud account to make calls, the bill is charged to the Alibaba Cloud account.
Billing examples
Example on how to calculate the number of API calls initiated to receive and deliver messages
An ApsaraMQ for RocketMQ broker receives seven million normal messages per day from a producer. The number of API calls that are initiated to deliver the messages is estimated to be eight million in view of the fact that a topic may be subscribed to by multiple groups and specific messages may be retried. The size of each message is 40 KB.
The ApsaraMQ for RocketMQ broker also receives three million advance-featured messages per day from a producer. The number of API calls that are initiated to deliver the messages is three million. The size of each message is 2 KB.
The total number of API calls that are initiated to receive and deliver messages per day is calculated by using the following formula: Number of API calls = (Number of API calls initiated to receive normal messages + Number of API calls initiated to deliver normal messages) × Multiplier for message size + (Number of API calls initiated to receive advance-featured messages + Number of API calls initiated to deliver advance-featured messages) × 5 × Multiplier for message size. Therefore, the total number of API calls that are initiated to receive and deliver messages per day is 180 million based on the following formula: (7 million + 8 million) × ⌈40/4⌉ + (3 million + 3 million) × 5 × ⌈2/4⌉ = 180 million.
Note⌈ ⌉ indicates that the value is rounded up to the next smallest integer.
Example on how to calculate API call fees
The following table describes the accumulated API calls that are initiated to receive and deliver messages and the tiered pricing schedule of an instance on which 500 million API calls are initiated to receive and deliver messages per day in the China (Shanghai) region.
Item
First day of the month
Second day of the month
Third day of the month
Fourth day of the month
...
Eleventh day of the month
...
Number of API calls initiated to receive and deliver messages on the day
500 million
500 million
500 million
500 million
...
500 million
...
Accumulated number of API calls
500 million
1 billion
1.5 billion
2 billion
...
5.5 billion
...
Unit price (USD per one million calls)
0.31 (first tier)
0.31 (first tier)
0.28 (second tier)
0.28 (second tier)
...
0.23 (third tier)
...
Fees on the day (USD)
155
155
140
140
...
115
...
Topic occupancy fees
Description
Topic occupancy fees = The price of a topic × Number of topics × Number of days
You are charged for occupying topics on ApsaraMQ for RocketMQ instances. Each topic is billed once every day. The prices of topics vary based on the number of API calls that are initiated to receive and deliver messages in the topic.
You are charged for each topic that you create, regardless of whether the topic is used. We recommend that you delete topics that you no longer require at the earliest opportunity to prevent unnecessary fees.
Unit prices
Prices at different tiers
Table 6. Topic occupancy fees Billing tier
Number of API calls initiated to receive and deliver messages (10,000 calls per topic-day)
Unit price by region (USD per topic-day)
China (Hong Kong), Singapore, Japan (Tokyo), UAE (Dubai), Australia (Sydney), US (Virginia), US (Silicon Valley), Germany (Frankfurt), and UK (London)
Malaysia (Kuala Lumpur), India (Mumbai), Indonesia (Jakarta), and Philippines (Manila)
Internet, China (Hangzhou), China (Shanghai), China (Shenzhen), China (Chengdu), China (Qingdao), China (Beijing), China (Zhangjiakou), and China (Hohhot)
SAU (Riyadh)
First tier
0 to 100
0.45
0.42
0.31
0.54
Second tier
100 to 500
0.34
0.31
0.23
0.408
Third tier
500 to 1,000
0.11
0.11
0.08
0.132
Fourth tier
> 1,000
0
0
0
0
Rules for tiered pricing
The tiered pricing schedule is based on the total number of API calls that are initiated to receive and deliver messages in the topic every day.
NoteIf you use an Alibaba Cloud account to authorize another Alibaba Cloud account by using a RAM role, the bill is charged to the authorizing Alibaba Cloud account. If you use an Alibaba Cloud account to authorize RAM users in the Alibaba Cloud account, the bill is charged to the Alibaba Cloud account.
Billing example
You create a specific number of topics on an instance that resides in the China (Shanghai) region.
You are charged for occupying topics on ApsaraMQ for RocketMQ instances. Each topic is billed once every day. The topic occupancy fees on a day is the sum of the fees that are generated by all topics that day.
Item | First day of the month | Second day of the month | Third day of the month | ... |
Topic_1 | The number of API calls that are initiated to receive and deliver messages: 100,000. The fees fall in the first tier. Topic occupancy fees: USD 0.31. | The number of API calls that are initiated to receive and deliver messages: 1.2 million. The fees fall in the second tier. Topic occupancy fees: USD 0.23. | The number of API calls that are initiated to receive and deliver messages: 300,000. The fees fall in the first tier. Topic occupancy fees: USD 0.31. | ... |
Topic_2 | The number of API calls that are initiated to receive and deliver messages: 5.5 million. The fees fall in the third tier. Topic occupancy fees: USD 0.08. | The number of API calls that are initiated to receive and deliver messages: 800,000. The fees fall in the first tier. Topic occupancy fees: USD 0.31. | The number of API calls that are initiated to receive and deliver messages: 100,000. The fees fall in the first tier. Topic occupancy fees: USD 0.31. | ... |
... | ... | ... | ... | ... |
Topic_n | ... | ... | ... | ... |
