Microservices Engine：從0搭建Java/Golang/Python應用並接入

Java

Golang

1. 環境配置：執行以下命令，使用最新的tag拉取Go版本的XXL-JOB的SDK。具體版本，參考xxl-job-executor-go。

   go get github.com/xxl-job/xxl-job-executor-go@{最新的tag}

2. 編寫初始化執行器。

   package main

   import (
       "context"
       "fmt"
       xxl "github.com/xxl-job/xxl-job-executor-go"
       "github.com/xxl-job/xxl-job-executor-go/example/task"
       "log"
   )

   func main() {
       exec := xxl.NewExecutor(
           xxl.ServerAddr("xxxxxx"),       //請求地址，控制台應用管理接入配置擷取
           xxl.AccessToken("xxxxxxx"),     //請求令牌，控制台應用管理接入配置擷取
           xxl.ExecutorPort("9999"),       //預設9999（非必填）
           xxl.RegistryKey("golang-jobs"), //執行器名稱
           xxl.SetLogger(&logger{}),       //自訂日誌
       )
       exec.Init()
       exec.Use(customMiddleware)
       //設定日誌查看handler
       exec.LogHandler(customLogHandle)
       //註冊任務handler
       exec.RegTask("task.test", task.Test)
       exec.RegTask("task.shardingTest", task.ShardingTest)
       log.Fatal(exec.Run())
   }

   // 自訂Tlog器
   func customLogHandle(req *xxl.LogReq) *xxl.LogRes {
       return &xxl.LogRes{Code: xxl.SuccessCode, Msg: "", Content: xxl.LogResContent{
           FromLineNum: req.FromLineNum,
           ToLineNum:   2,
           LogContent:  "這個是自訂日誌handler",
           IsEnd:       true,
       }}
   }

   // xxl.Logger介面實現
   type logger struct{}

   func (l *logger) Info(format string, a ...interface{}) {
       fmt.Println(fmt.Sprintf("自訂日誌 - "+format, a...))
   }

   func (l *logger) Error(format string, a ...interface{}) {
       log.Println(fmt.Sprintf("自訂日誌 - "+format, a...))
   }

   // 自訂中介軟體
   func customMiddleware(tf xxl.TaskFunc) xxl.TaskFunc {
       return func(cxt context.Context, param *xxl.RunReq) string {
           log.Println("I am a middleware start")
           res := tf(cxt, param)
           log.Println("I am a middleware end")
           return res
       }
   }

3. 編寫任務執行代碼。

   package task

   import (
   	"context"
   	"fmt"
   	xxl "github.com/xxl-job/xxl-job-executor-go"
   )

   func Test(cxt context.Context, param *xxl.RunReq) (msg string) {
   	fmt.Println("test one task" + param.ExecutorHandler + " param：" + param.ExecutorParams + " log_id:" + xxl.Int64ToStr(param.LogID))
   	return "test done"
   }

   func ShardingTest(cxt context.Context, param *xxl.RunReq) (msg string) {
   	fmt.Println("shardingId:" + xxl.Int64ToStr(param.BroadcastIndex) + ", shardingTotal:" + xxl.Int64ToStr(param.BroadcastTotal))
   	return "ShardingTest done"
   }

Python

1. 拉取依賴。具體版本，參考xxl-job-executor-python。

   pip install pyxxl

   # 如果日誌需要寫入redis
   pip install "pyxxl[redis]"

   # 如果需要從.env載入配置
   pip install "pyxxl[dotenv]"

   # 安裝所有功能
   pip install "pyxxl[all]"

2. 編寫任務執行代碼。

   import asyncio
   import time

   from pyxxl import ExecutorConfig, PyxxlRunner
   from pyxxl.ctx import g

   config = ExecutorConfig(
       xxl_admin_baseurl="http://xxljob-1b3fd81****.schedulerx.mse.aliyuncs.com/api/",
       executor_app_name="xueren-test",
       access_token="default_token",
       # executor_listen_host="0.0.0.0",  # 如果xxl-admin可以直連executor的ip，可以不填寫executor_listen_host
   )

   app = PyxxlRunner(config)


   @app.register(name="demoJobHandler")
   async def test_task():
       # you can get task params with "g"
       g.logger.info("get executor params: %s" % g.xxl_run_data.executorParams)
       for i in range(10):
           g.logger.warning("test logger %s" % i)
       await asyncio.sleep(5)
       return "成功..."

   @app.register(name="sync_func")
   def test_task4():
       # 如果要在xxl-admin上看到執行日誌，列印日誌的時候務必用g.logger來列印，預設只列印info及以上的日誌
       n = 1
       g.logger.info("Job %s get executor params: %s" % (g.xxl_run_data.jobId, g.xxl_run_data.executorParams))
       # 如果同步任務裡面有迴圈，為了支援cancel操作，必須每次都判斷g.cancel_event.
       while n <= 10 and not g.cancel_event.is_set():
           # 如果不需要從xxl-admin中查看日誌，可以用自己的logger
           g.logger.info(
               "log to {} logger test_task4.{},params:{}".format(
                   g.xxl_run_data.jobId,
                   n,
                   g.xxl_run_data.executorParams,
               )
           )
           time.sleep(2)
           n += 1
       return "成功3"


   if __name__ == "__main__":
       app.run_executor()
