Auto Scaling:Buat sumber daya Auto Scaling menggunakan Terraform

Sumber daya yang digunakan

Buat sumber daya Auto Scaling

Pada contoh ini, Anda akan membuat sumber daya Auto Scaling, termasuk grup penskalaan, konfigurasi penskalaan, dan aturan penskalaan.

1. Buat direktori kerja, buat file konfigurasi bernama main.tf, lalu salin kode berikut ke dalam main.tf.

   variable "region" {
     default = "cn-heyuan"
   }
   variable "instance_type" {
     default = "ecs.hfc7.xlarge"
   }
   variable "image_id" {
     default = "aliyun_2_1903_x64_20G_alibase_20210120.vhd"
   }
   variable "zone_id" {
     default = "cn-heyuan-b"
   }
   provider "alicloud" {
     region = var.region
   }
   # Create a VPC.
   resource "alicloud_vpc" "vpc" {
     vpc_name   = "tf-test-vpc-wjt"
     cidr_block = "172.16.0.0/12" # Specify the private CIDR block for the VPC.
   }
   # Create a vSwitch.
   resource "alicloud_vswitch" "vsw" {
     vpc_id       = alicloud_vpc.vpc.id
     cidr_block   = "172.16.0.0/21" # Specify the private CIDR block for the vSwitch.
     zone_id      = var.zone_id     # Select the zone for the vSwitch.
     vswitch_name = "tf-test-vswitch-wjt"
   }
   # Create a security group.
   resource "alicloud_security_group" "security" {
     name        = "tf_test_security"
     description = "New security group"
     vpc_id      = alicloud_vpc.vpc.id
   }
   # Add a security group rule that allows traffic from all IP addresses.
   resource "alicloud_security_group_rule" "allow_all_tcp" {
     type              = "ingress"
     ip_protocol       = "tcp"
     nic_type          = "intranet"
     policy            = "accept"
     port_range        = "1/65535"
     priority          = 1
     security_group_id = alicloud_security_group.security.id
     cidr_ip           = "0.0.0.0/0"
   }
   # This example creates a scaling group with a maximum of 100 instances.
   resource "alicloud_ess_scaling_group" "group" {
     scaling_group_name = "tf_test_scalinggroup"
     min_size           = 0
     max_size           = 100
     vswitch_ids        = [alicloud_vswitch.vsw.id]
   }
   # This example creates a scaling configuration for ECS instances.
   resource "alicloud_ess_scaling_configuration" "configuration" {
     scaling_group_id           = alicloud_ess_scaling_group.group.id
     instance_type              = var.instance_type
     image_id                   = var.image_id
     security_group_id          = alicloud_security_group.security.id
     scaling_configuration_name = "tf_test_scalingconfiguration"
     system_disk_category       = "cloud_essd"
     spot_strategy              = "SpotWithPriceLimit"
     active                     = true
     force_delete               = true
   }
   # Create a scaling rule.
   resource "alicloud_ess_scaling_rule" "rule" {
     scaling_group_id = alicloud_ess_scaling_group.group.id
     adjustment_type  = "QuantityChangeInCapacity"
     adjustment_value = 1
   }

2. Jalankan perintah berikut untuk menginisialisasi lingkungan runtime Terraform.

   terraform init

   Output berikut menunjukkan bahwa inisialisasi berhasil.

   Initializing the backend...
   Initializing provider plugins...
   - Checking for available provider plugins...
   - Downloading plugin for provider "alicloud" (hashicorp/alicloud) 1.90.1...
   ...
   You may now begin working with Terraform. Try running "terraform plan" to see
   any changes that are required for your infrastructure. All Terraform commands
   should now work.
   If you ever set or change modules or backend configuration for Terraform,
   rerun this command to reinitialize your working directory. If you forget, other
   commands will detect it and remind you to do so if necessary.

3. Buat rencana eksekusi dan pratinjau perubahan.

   terraform plan

4. Jalankan perintah berikut untuk membuat sumber daya.

   terraform apply

   Saat diminta, ketik yes dan tekan Enter. Tunggu hingga perintah selesai. Output berikut menunjukkan bahwa sumber daya Auto Scaling telah dibuat.

   Do you want to perform these actions?
     Terraform will perform the actions described above.
     Only 'yes' will be accepted to approve.
     Enter a value: yes
   ...
   alicloud_security_group_rule.allow_all_tcp: Creation complete after 0s [id=sg-f8z1mes******:ingress:tcp:1/65535:intranet:0.0.0.0/0:accept:1]
   alicloud_vswitch.vsw: Creation complete after 3s [id=vsw-f8ztgc4******]
   alicloud_ess_scaling_group.group: Creating...
   alicloud_ess_scaling_group.group: Creation complete after 2s [id=asg-f8z9mo******]
   ...
   Apply complete! Resources: 7 added, 0 changed, 0 destroyed.

5. Verifikasi hasil

   Terraform show

   Jalankan perintah berikut untuk melihat detail sumber daya yang dibuat oleh Terraform:

   terraform show

   D:\tf>terraform show
   # alicloud_ess_scaling_configuration.configuration:
   resource "alicloud_ess_scaling_configuration" "configuration" {
       active                         = true
       credit_specification           = null
       force_delete                   = true
       host_name                      = null
       id                             = "xxx"
       image_id                       = "aliyun_2_1903_x64_20G_alibase_20210120.vhd"
       image_name                     = null
       instance_name                  = "ESS-Instance"
       instance_type                  = "ecs.hfc7.xlarge"
       internet_charge_type           = "PayByBandwidth"
       internet_max_bandwidth_in      = 0
       internet_max_bandwidth_out     = 0
       key_name                       = null
       override                       = false
       password_inherit                = false
       resource_group_id              = null
       role_name                      = null
       scaling_configuration_name     = "tf_test_scalingconfiguration"
       scaling_group_id               = "xxx"
       security_group_id              = "xxx"
       spot_strategy                  = "SpotWithPriceLimit"
       ...
       system_disk_auto_snapshot_policy_id = null
       system_disk_category           = "cloud_essd"
       system_disk_description        = null
       system_disk_encrypted          = false
       system_disk_name               = null
       system_disk_performance_level  = null
       system_disk_size               = 0
   }
   # alicloud_ess_scaling_group.group:
   resource "alicloud_ess_scaling_group" "group" {
       allocation_strategy                    = null
       az_balance                             = false
       default_cooldown                       = 300
       desired_capacity                       = 0
       group_deletion_protection              = false
       group_type                             = "ECS"
       health_check_type                      = "ECS"
       id                                     = "asg-xxx"
       launch_template_id                     = null
       launch_template_version                = null
       max_size                               = 100
       min_size                               = 0
       multi_az_policy                        = "PRIORITY"
       on_demand_base_capacity                = 0
       on_demand_percentage_above_base_capacity = 0
       removal_policies                       = [
           "OldestScalingConfiguration",
           "OldestInstance",
       ]
       resource_group_id                      = "xxx"
       scaling_group_name                     = "tf_test_scalinggroup"
       scaling_policy                         = "release"
       spot_allocation_strategy               = null
       spot_instance_remedy                   = false
       vswitch_ids                            = [
           "vsw-f8ztgc4ad3e7ft9evy38z",
       ]
   }

   Konsol Auto Scaling

   Login ke Auto Scaling console untuk melihat grup penskalaan yang telah Anda buat.

   Pada bilah navigasi atas, pilih China (Heyuan) dari pemilih wilayah. Pada halaman Scaling Groups, temukan grup penskalaan bernama tf_test_scalinggroup dan pastikan statusnya Disabled, jenisnya ECS, serta jumlah maksimum instansnya 100.

Bersihkan sumber daya

Saat Anda tidak lagi memerlukan sumber daya yang dibuat dan dikelola oleh Terraform, jalankan perintah berikut untuk menghapusnya. Untuk informasi selengkapnya tentang terraform destroy, lihat Common commands.

terraform destroy
