ApsaraVideo Live:Generate ingest and streaming URLs

Ingest URLs

Concatenation rule: Ingest domain + AppName + StreamName + {Access token}

• AppName and StreamName can be customized.

  ApsaraVideo Live determines whether a stream is unique based on StreamName instead of AppName. To distinguish two streams, their stream names must be different.

  If you want to use different AppNames under the same domain to ingest an identical stream (StreamName), contact us to enable app isolation.

• {Access token} is an encrypted string calculated by MD5 algorithm. For more information, see Structure of the access token.

Examples:

• RTMP: rtmp://demo.aliyundoc.com/app/stream?auth_key={Access token}

• ARTC: artc://demo.aliyundoc.com/app/stream?auth_key= {Access token}

  • The ARTC URL is used for Real-Time Streaming (RTS).

• SRT: srt://demo.aliyundoc.com:1105?streamid=#!::h=demo.aliyundoc.com,r=/app/stream?auth_key= {Access token} ,m=publish

  • By default, the SRT protocol is disabled. To enable it, see Configure stream ingest over SRT.

  • The access token does not include m=publish.

Streaming URLs

In addition to standard streams, ApsaraVideo Live supports playing processed ones, including transcoded, delayed, and transcribed streams. The concatenation rules and supported protocols vary by stream type.

Generate URLs in the console

You can use Live URL generator to do this.

You must first associate an ingest domain with a streaming domain.

The generated URLs contain the access tokens.

Generate URLs using code

Step 1: Get the encryption key

Before generating a signed URL, you must retrieve the key for encryption.

• To generate ingest URLs, get the key of the ingest domain.

• To generate streaming URLs, get the key of the streaming domain.

You can retrieve both in the console or by calling DescribeLiveDomainConfigs.

// Replace the placeholder values in brackets with actual values.
DefaultProfile profile = DefaultProfile.getProfile("<regionId>", "<ALIBABA_CLOUD_ACCESS_KEY_ID>", "<ALIBABA_CLOUD_ACCESS_KEY_SECRET>");
IAcsClient client = new DefaultAcsClient(profile);
DescribeLiveDomainConfigsRequest describeLiveDomainConfigsRequest=new DescribeLiveDomainConfigsRequest();
describeLiveDomainConfigsRequest.setDomainName("<DomainName>");
describeLiveDomainConfigsRequest.setFunctionNames("aliauth");

DescribeLiveDomainConfigsResponse describeLiveStreamSnapshotInfoResponse = null;
try {
     describeLiveStreamSnapshotInfoResponse = client.getAcsResponse(describeLiveDomainConfigsRequest);
 } catch (ClientException e) {
     e.printStackTrace();
}
// Key
String key="";


for(DescribeLiveDomainConfigsResponse.DomainConfig.FunctionArg f:describeLiveStreamSnapshotInfoResponse.getDomainConfigs().get(0).getFunctionArgs()){
     if("auth_key1".equals(f.getArgName())){
            key=f.getArgValue();
      }
}

System.out.println(key);



Step 2: Generate signed URLs

The following sample code shows how to generate a signed URL using the RTMP protocol.

Before generation, learn about the composition of a signed URL.

import java.math.BigInteger;
import java.nio.charset.StandardCharsets;
import java.security.MessageDigest;
import java.security.NoSuchAlgorithmException;
import java.util.regex.Matcher;
import java.util.regex.Pattern;

public class AuthDemo {
    private static String md5Sum(String src) {
        MessageDigest md5 = null;
        try {
            md5 = MessageDigest.getInstance("MD5");
        } catch (NoSuchAlgorithmException e) {
            e.printStackTrace();
        }
        md5.update(StandardCharsets.UTF_8.encode(src));
        return String.format("%032x", new BigInteger(1, md5.digest()));
    }

private static String aAuth(String uri, String key, long exp) {
    String pattern = "^(rtmp://)?([^/?]+)(/[^?]*)?(\\\\?.*)?$";
    Pattern r = Pattern.compile(pattern);
    Matcher m = r.matcher(uri);
    String scheme = "", host = "", path = "", args = "";
    if (m.find()) {
        scheme = m.group(1) == null ? "rtmp://" : m.group(1);
        host = m.group(2) == null ? "" : m.group(2);
        path = m.group(3) == null ? "/" : m.group(3);
        args = m.group(4) == null ? "" : m.group(4);
    } else {
        System.out.println("NO MATCH");
    }

    String rand = "0";  // "0" By default, other value is ok
    String uid = "0";   // "0" By default, other value is ok
    String sString = String.format("%s-%s-%s-%s-%s", path, exp, rand, uid, key);
    String hashValue = md5Sum(sString);
    String authKey = String.format("%s-%s-%s-%s", exp, rand, uid, hashValue);
    if (args.isEmpty()) {
        return String.format("%s%s%s%s?auth_key=%s", scheme, host, path, args, authKey);
    } else {
        return String.format("%s%s%s%s&auth_key=%s", scheme, host, path, args, authKey);
    }
}

public static void main(String[] args) {
    // The URL to be encrypted. In the following example, the domain name is example.aliyundoc.com, AppName is liveApp, and StreamName is liveStream.
    // Ingest and streaming URLs are encrypted using the same method.
    // AppName and StreamName support letters, digits, hyphens (-), underscores (_), and equal signs (=). The maximum length is 256 characters.
    String uri = "rtmp://example.aliyundoc.com/liveApp/liveStream";
    // The key. To generate an ingest URL, use the key of the ingest domain. To generate a streaming URL, use the key of the streaming domain.
    String key = "<input private key>";
    // The exp value is a UNIX timestamp measured in seconds. The actual expiration time equals the exp value + the validity period set for the domain name.
    // For example, if you set exp to current time + 3600 seconds, the actual expiration time equals the current time + 3600 seconds + the validity period. If you set it to the current time, the expiration time is the current time + the validity period.
    long exp = System.currentTimeMillis() / 1000 + 1 * 3600;
    String authUri = aAuth(uri, key, exp);
    System.out.printf("URL : %s\nAuth: %s", uri, authUri);
}
}

import re
import time
import hashlib
import datetime
def md5sum(src):
    m = hashlib.md5()
    m.update(src)
    return m.hexdigest()
def a_auth(uri, key, exp):
    p = re.compile("^(rtmp://)?([^/?]+)(/[^?]*)?(\\?.*)?$")
    if not p:
        return None
    m = p.match(uri)
    scheme, host, path, args = m.groups()
    if not scheme: scheme = "rtmp://"
    if not path: path = "/"
    if not args: args = ""
    rand = "0"      # "0" By default, other value is ok
    uid = "0"       # "0" By default, other value is ok
    sstring = "%s-%s-%s-%s-%s" %(path, exp, rand, uid, key)
    hashvalue = md5sum(sstring.encode('utf-8'))
    auth_key = "%s-%s-%s-%s" %(exp, rand, uid, hashvalue)
    if args:
        return "%s%s%s%s&auth_key=%s" %(scheme, host, path, args, auth_key)
    else:
        return "%s%s%s%s?auth_key=%s" %(scheme, host, path, args, auth_key)
def main():
    # The URL to be encrypted. In the following example, the domain name is example.aliyundoc.com, AppName is liveApp, and StreamName is liveStream.
    # Ingest and streaming URLs are encrypted using the same method.
    # AppName and StreamName support letters, digits, hyphens (-), underscores (_), and equal signs (=). The maximum length is 256 characters.
    uri = "rtmp://example.aliyundoc.com/liveApp/liveStream"
    # The key. To generate an ingest URL, use the key of the ingest domain. To generate a streaming URL, use the key of the streaming domain.
    key = "<input private key>"
    # The exp value is a UNIX timestamp measured in seconds. The actual expiration time equals the exp value + the validity period set for the domain name.
    # For example, if you set exp to current time + 3600 seconds, the actual expiration time equals the current time + 3600 seconds + the validity period. If you set it to the current time, the expiration time is the current time + the validity period.
    exp = int(time.time()) + 1 * 3600
    authuri = a_auth(uri, key, exp)
    print("URL : %s\nAUTH: %s" %(uri, authuri))
if __name__ == "__main__":
    main()

package main
import (
    "crypto/md5"
    "encoding/hex"
    "fmt"
    "regexp"
    "time"
)

func md5sum(src string) string {
    h := md5.New()
    h.Write([]byte(src))
    return hex.EncodeToString(h.Sum(nil))
}

func a_auth(uri, key string, exp int64) string {
    p, err := regexp.Compile("^(rtmp://)?([^/?]+)(/[^?]*)?(\\?.*)?$")
    if err != nil {
        fmt.Println(err)
        return ""
    }
    m := p.FindStringSubmatch(uri)
    var scheme, host, path, args string
    if len(m) == 5 {
        scheme, host, path, args = m[1], m[2], m[3], m[4]
    } else {
        scheme, host, path, args = "rtmp://", "", "/", ""
    }
    rand := "0" // "0" by default, other value is ok
    uid := "0"  // "0" by default, other value is ok
    sstring := fmt.Sprintf("%s-%d-%s-%s-%s", path, exp, rand, uid, key)
    hashvalue := md5sum(sstring)
    auth_key := fmt.Sprintf("%d-%s-%s-%s", exp, rand, uid, hashvalue)
    if len(args) != 0 {
        return fmt.Sprintf("%s%s%s%s&auth_key=%s", scheme, host, path, args, auth_key)
    } else {
        return fmt.Sprintf("%s%s%s%s?auth_key=%s", scheme, host, path, args, auth_key)
    }
}

func main() {
    // The URL to be encrypted. In the following example, the domain name is example.aliyundoc.com, AppName is liveApp, and StreamName is liveStream.
    // Ingest and streaming URLs are encrypted using the same method.
    // AppName and StreamName support letters, digits, hyphens (-), underscores (_), and equal signs (=). The maximum length is 256 characters.
    uri := "rtmp://example.aliyundoc.com/liveApp/liveStream"
    // The key. To generate an ingest URL, use the key of the ingest domain. To generate a streaming URL, use the key of the streaming domain.
    key := "<input private key>"
    // The exp value is a UNIX timestamp measured in seconds. The actual expiration time equals the exp value + the validity period set for the domain name.
    // For example, if you set exp to current time + 3600 seconds, the actual expiration time equals the current time + 3600 seconds + the validity period. If you set it to the current time, the expiration time is the current time + the validity period.
    exp := time.Now().Unix() + 3600
    authuri := a_auth(uri, key, exp)
    fmt.Printf("URL : %s\nAUTH: %s", uri, authuri)
}

<?php
function a_auth($uri, $key, $exp) {
    preg_match("/^(rtmp:\/\/)?([^\/?]+)?(\/[^?]*)?(\\?.*)?$/", $uri, $matches);
    $scheme = $matches[1];
    $host = $matches[2];
    $path = $matches[3];
    $args = $matches[4];
    if  (empty($args)) {
        $args ="";
    }
    if  (empty($scheme)) {
        $scheme ="rtmp://";
    }
    if  (empty($path)) {
        $path ="/";
    }
    $rand = "0";
    // "0" by default, other value is ok
    $uid = "0";
    // "0" by default, other value is ok
    $sstring = sprintf("%s-%u-%s-%s-%s", $path, $exp, $rand, $uid, $key);
    $hashvalue = md5($sstring);
    $auth_key = sprintf("%u-%s-%s-%s", $exp, $rand, $uid, $hashvalue);
    if ($args) {
        return sprintf("%s%s%s%s&auth_key=%s", $scheme, $host, $path, $args, $auth_key);
    } else {
        return sprintf("%s%s%s%s?auth_key=%s", $scheme, $host, $path, $args, $auth_key);
    }
}
// The URL to be encrypted. In the following example, the domain name is example.aliyundoc.com, AppName is liveApp, and StreamName is liveStream.
// Ingest and streaming URLs are encrypted using the same method.
// AppName and StreamName support letters, digits, hyphens (-), underscores (_), and equal signs (=). The maximum length is 256 characters.
$uri = "rtmp://example.aliyundoc.com/liveApp/liveStream";
// The key. To generate an ingest URL, use the key of the ingest domain. To generate a streaming URL, use the key of the streaming domain.
$key = "<input private key>";
// The exp value is a UNIX timestamp measured in seconds. The actual expiration time equals the exp value + the validity period set for the domain name.
// For example, if you set exp to current time + 3600 seconds, the actual expiration time equals the current time + 3600 seconds + the validity period. If you set it to the current time, the expiration time is the current time + the validity period.
$exp = time() + 3600;
$authuri = a_auth($uri, $key, $exp);
echo "URL :" . $uri;
echo PHP_EOL;
echo "AUTH:" . $authuri;
?>

using System;
using System.Text.RegularExpressions;
using System.Security.Cryptography;
using System.Text;
public class Test
{
    public static void Main()
    {
        // The URL to be encrypted. In the following example, the domain name is example.aliyundoc.com, AppName is liveApp, and StreamName is liveStream.
        // Ingest and streaming URLs are encrypted using the same method.
        // AppName and StreamName support letters, digits, hyphens (-), underscores (_), and equal signs (=). The maximum length is 256 characters.
        string uri= "rtmp://example.aliyundoc.com/liveApp/liveStream";
        // The key. To generate an ingest URL, use the key of the ingest domain. To generate a streaming URL, use the key of the streaming domain.
        string key= "<input private key>";
        DateTime dateStart = new DateTime(1970, 1, 1, 8, 0, 0);
        // The exp value is a UNIX timestamp measured in seconds. The actual expiration time equals the exp value + the validity period set for the domain name.
        // For example, if you set exp to current time + 3600 seconds, the actual expiration time equals the current time + 3600 seconds + the validity period. If you set it to the current time, the expiration time is the current time + the validity period.
        string exp  = Convert.ToInt64((DateTime.Now - dateStart).TotalSeconds+3600).ToString();
        string authUri = aAuth(uri, key, exp);
        Console.WriteLine (String.Format("URL :{0}",uri));
        Console.WriteLine (String.Format("AUTH :{0}",authUri));
    }
    public static string aAuth(string uri, string key, string exp)
    {
        Regex regex = new Regex("^(rtmp://)?([^/?]+)(/[^?]*)?(\\\\?.*)?$");
        Match m = regex.Match(uri);
        string scheme = "rtmp://", host = "", path = "/", args = "";
        if (m.Success)
        {
            scheme=m.Groups[1].Value;
            host=m.Groups[2].Value;
            path=m.Groups[3].Value;
            args=m.Groups[4].Value;
        }else{
            Console.WriteLine ("NO MATCH");
        }
        string rand = "0";  // "0" by default, other value is ok
        string uid = "0";   // "0" by default, other value is ok
        string u = String.Format("{0}-{1}-{2}-{3}-{4}",  path, exp, rand, uid, key);
        string hashValue  = Md5(u);
        string authKey = String.Format("{0}-{1}-{2}-{3}", exp, rand, uid, hashValue);
        if (args=="")
        {
            return String.Format("{0}{1}{2}{3}?auth_key={4}", scheme, host, path, args, authKey);
        } else
        {
            return String.Format("{0}{1}{2}{3}&auth_key={4}", scheme, host, path, args, authKey);
        }
    }
    public static string Md5(string value)
    {
        MD5CryptoServiceProvider md5 = new MD5CryptoServiceProvider();
        byte[] bytes = Encoding.ASCII.GetBytes(value);
        byte[] encoded = md5.ComputeHash(bytes);
        StringBuilder sb = new StringBuilder();
        for(int i=0; i<encoded.Length; ++i)
        {
            sb.Append(encoded[i].ToString("x2"));
        }
        return sb.ToString();
   }
}
