ApsaraVideo VOD:Use the diagnostic tool

Last Updated:Jan 20, 2022

This topic describes how to access and use the diagnostic tool that is provided by ApsaraVideo Player to troubleshoot a video.

Prerequisites

Make sure that you have completed the following settings:

  • Enable Referer-based hotlink protection for the streaming domain name and add player.alicdn.com to the whitelist. For more information, see IP address blacklist or whitelist.

    Note

    player.alicdn.com is the address of ApsaraVideo Player. You must add this address to the whitelist.

    Add an IP address to the whitelist
  • Add Access-Control-Allow-Origin to the HTTP message header for the streaming domain name. For more information, see Configure CORS.

Procedure

  1. Access the diagnostic tool.

    You can access the diagnostic tool that is provided by ApsaraVideo Player by using one of the following methods:

    • If an error occurs when a video is played, click diagnosis to go to the diagnostic tool page.Web player-Use diagnostic tool 2

    • Visit Diagnostic tool.

  2. Check basic information.

    On the Diagnostic information tab, information about your environment such as the operating system, browser, IP address, and operator is displayed.Web player-Use diagnostic tool 3

  3. Diagnose video playback.

    1. On the Video play tab, select a video playback method. The following playback methods are supported: Native H5, Aliyun H5, and Aliyun Flash.

    2. Specify the Source parameter (video playback URL) and click play to start the tool. If the Source parameter is not specified, you can specify the Vid and playAuth parameters.

      Note

      The Source parameter has the highest priority.

    3. View the playback log after the tool is started.Web player-Use diagnostic tool
