This topic describes how to extend the file system of a Linux data disk. Resizing a cloud disk does not extend the file system; it only extends the storage capacity. Therefore, you need to format the newly extended storage capacity after you resize a cloud disk.

Limits

The information contained in this topic applies only to disks that are attached to ECS instances (that is, the cloud disk is in a state other than Available). For information on how to attach, partition, or format disks that are in the Available state, see Attach a cloud disk and Partition and format a data disk.

Scenarios

Table 1. Scenarios for resizing a data disk of a Linux instance
Scenario Operation
The data disk is attached to the instance. The data disk is partitioned and formatted. You can follow the relevant procedure described in this topic to resize the data disk.
The data disk is empty and is not partitioned or formatted. After you resize the data disk in the ECS console, you can follow the relevant procedure describe in this topic to partition and format the data disk.
The data disk is formatted but not partitioned. After you resize the data disk in the ECS console, you can follow the procedure to extend the file system.
The data disk is not attached to the instance. You can resize the data disk offline, or you can resize the data disk after you attach it to the instance.

In this example, the data disk is an ultra disk and the operating system of the ECS instance is CentOS 7.5 64-bit. The mount point of the data disk is /dev/vdb and the existing partition is /dev/vdb1. The data disk capacity before resizing is 20 GiB whereas the data disk capacity after resizing is 40 GiB. The data disk is attached to the instance and is partitioned and formatted.

Preparations

  1. Use the ECS console or call the API ResizeDisk to resize the cloud disk.
  2. Create a snapshot to back up your data.
  3. Attach the cloud disk to the instance and make sure that the instance is in the Running state. For information about the connection methods, see Overview.

Check the partition and file system

  1. Run the fdisk -lu <DeviceName> command to check whether the data disk is partitioned.
    In this example, the data disk has the partition /dev/vdb1.
    [root@localhost ~]# fdisk -lu /dev/vdb
    Disk /dev/vdb: 42.9 GB, 42949672960 bytes, 83886080 sectors
    Units = sectors of 1 * 512 = 512 bytes
    Sector size (logical/physical): 512 bytes / 512 bytes
    I/O size (minimum/optimal): 512 bytes / 512 bytes
    Disk label type: dos
    Disk identifier: 0x9277b47b

    Device Boot Start End Blocks Id System
    /dev/vdb1 2048 41943039 20970496 83 Linux
  2. Run the blkid <PartionName> command to check the file system type.
    In this example, the file system type of /dev/vdb1 is ext4.
    [root@localhost ~]# blkid /dev/vdb1
    /dev/vdb1: UUID="e97bf1e2-fc84-4c11-9652-73554546c324" TYPE="ext4"
    Note If the data disk is not partitioned or formatted, or if the data disk is partitioned but not formatted, no response message is returned.
  3. Run the following command to check the status of the file system:
    • For ext file systems: e2fsck -n <dst_dev_part_path>
    • For XFS file systems: xfs_repair -n <dst_dev_part_path>

    In this example, the file system is in the clean state.

    [root@localhost ~]# e2fsck -n /dev/vdb1
    e2fsck 1.42.9 (28-Dec-2013)
    Warning! /dev/vdb1 is mounted.
    Warning: skipping journal recovery because doing a read-only filesystem check.
    /dev/vdb1: clean, 11/1310720 files, 126322/5242624 blocks
Note If the data disk is not partitioned or formatted, you need to partition and format it. For more information, see Format a data disk of a Linux instance.

Procedure 1: Extend the existing partition

To avoid data loss, we recommend that you do not resize a mounted ( mount) partition or file system. Instead, we recommend that you unmount ( umount) the partition first, and then re-mount ( mount) the partition after you extend it. If you do need to extend a mounted partition, follow these instructions according to the kernel version of the target instance:
  • If the kernel version of the instance is earlier than v3.6, unmount the partition, and then modify the partition table by following Step 1: Modify the partition table as detailed in the next section.
  • If the kernel version of the instance is later than v3.6, you need to update the kernel information after you modify the partition table.

To use the new disk space to extend the existing partition, follow these steps:

Step 1: Modify the partition table

  1. Run the fdisk -lu /dev/vdb command and note down the start sector and end sector of the old partition.
    In this example, the start sector of /dev/vdb1 is 2048 and the end sector is 41943039.
    [root@localhost ~]# fdisk -lu /dev/vdb
    Disk /dev/vdb: 42.9 GB, 42949672960 bytes, 83886080 sectors
    Units = sectors of 1 * 512 = 512 bytes
    Sector size (logical/physical): 512 bytes / 512 bytes
    I/O size (minimum/optimal): 512 bytes / 512 bytes
    Disk label type: dos
    Disk identifier: 0x9277b47b

    Device Boot Start End Blocks Id System
    /dev/vdb1 2048 41943039 20970496 83 Linux
  2. Run the fdisk command to delete the old partition.
    1. Run the fdisk -u /dev/vdb command to partition the data disk.
    2. Enter p to print the partition table.
    3. Enter d to delete the partition.
    4. Enter p to confirm that the partition is deleted.
    5. Enter w to save your modifications and exit.
    [root@localhost ~]# fdisk -u /dev/vdb
    Welcome to fdisk (util-linux 2.23.2).
    Changes will remain in memory only, until you decide to write them.
    Be careful before using the write command.
    Command (m for help): p
    Disk /dev/vdb: 42.9 GB, 42949672960 bytes, 83886080 sectors
    Units = sectors of 1 * 512 = 512 bytes
    Sector size (logical/physical): 512 bytes / 512 bytes
    I/O size (minimum/optimal): 512 bytes / 512 bytes
    Disk label type: dos
    Disk identifier: 0x9277b47b
    Device Boot Start End Blocks Id System
    /dev/vdb1 2048 41943039 20970496 83 Linux
    Command (m for help): d
    Selected partition 1
    Partition 1 is deleted
    Command (m for help): p
    Disk /dev/vdb: 42.9 GB, 42949672960 bytes, 83886080 sectors
    Units = sectors of 1 * 512 = 512 bytes
    Sector size (logical/physical): 512 bytes / 512 bytes
    I/O size (minimum/optimal): 512 bytes / 512 bytes
    Disk label type: dos
    Disk identifier: 0x9277b47b
    Device Boot Start End Blocks Id System
    Command (m for help): w
    The partition table has been altered!
    Calling ioctl() to re-read partition table.
    WARNING: Re-reading the partition table failed with error 16: Device or resource busy.
    The kernel still uses the old table. The new table will be used at
    the next reboot or after you run partprobe(8) or kpartx(8)
    Syncing disks.
  3. Run the fdisk command to create a partition.
    1. Run the fdisk -u /dev/vdb command to partition the data disk.
    2. Enter p to print the partition table.
    3. Enter n to create a partition.
    4. Enter p to set the partition type to primary partition.
    5. Enter <partition number> to select a partition number. In this example, select 1.
      Warning
      • The start sector of the new partition must be the same as that of the old partition.
      • The end sector of the new partition must be greater than that of the old partition. Otherwise, the disk resizing operation fails.
    6. Enter w to save your modifications and exit.

    In this example, the /dev/vdb1 partition is extended from 20 GiB to 40 GiB.

    logical[root@localhost ~]# fdisk -u /dev/vdb
    Welcome to fdisk (util-linux 2.23.2).
    Changes will remain in memory only, until you decide to write them.
    Be careful before using the write command.
    Command (m for help): p
    Disk /dev/vdb: 42.9 GB, 42949672960 bytes, 83886080 sectors
    Units = sectors of 1 * 512 = 512 bytes
    Sector size (logical/physical): 512 bytes / 512 bytes
    I/O size (minimum/optimal): 512 bytes / 512 bytes
    Disk label type: dos
    Disk identifier: 0x9277b47b
    Device Boot Start End Blocks Id System
    Command (m for help): n
    Partition type:
    p primary (0 primary, 0 extended, 4 free)
    e extended
    Select (default p): p
    Partition number (1-4, default 1): 1
    First sector (2048-83886079, default 2048):
    Using default value 2048
    Last sector, +sectors or +size{K,M,G} (2048-83886079, default 83886079):
    Partition 1 of type Linux and of size 30 GiB is set
    Command (m for help): p
    Disk /dev/vdb: 42.9 GB, 42949672960 bytes, 83886080 sectors
    Units = sectors of 1 * 512 = 512 bytes
    Sector size (logical/physical): 512 bytes / 512 bytes
    I/O size (minimum/optimal): 512 bytes / 512 bytes
    Disk label type: dos
    Disk identifier: 0x9277b47b
    Device Boot Start End Blocks Id System
    /dev/vdb1 2048 62916607 31457280 83 Linux
    Command (m for help): w
    The partition table has been altered!
    Calling ioctl() to re-read partition table.

    WARNING: Re-reading the partition table failed with error 16: Device or resource busy.
    The kernel still uses the old table. The new table will be used at
    the next reboot or after you run partprobe(8) or kpartx(8)
    Syncing disks.
  4. Run the e2fsck -n /dev/vdb1 command to check the file system to confirm the file system is in the clean state.

Step 2: Update the kernel information

If the kernel version of the instance is later than v3.6, after you modify the partition table, run the partprobe <dst_dev_path> or partx -u <dst_dev_path> command to update the kernel information.

Step 3: Extend the file system

  • To extend an ext file system (for example, ext3 or ext4), run the resize2fs /dev/vdb1 command.
    [root@localhost ~]# resize2fs /dev/vdb1
    resize2fs 1.42.9 (28-Dec-2013)
    Resizing the filesystem on /dev/vdb1 to 7864320 (4k) blocks.
    The filesystem on /dev/vdb1 is now 7864320 blocks long.
  • To extend an XFS file system, run the mount /dev/vdb1 /mnt/ command, and then run the xfs_growfs /dev/vdb1 command.
    [root@localhost ~]# mount /dev/vdb1 /mnt/
    [root@localhost ~]# xfs_growfs /dev/vdb1

    meta-data=/dev/vdb1              isize=512    agcount=4, agsize=1310720 blks
             =                       sectsz=512   attr=2, projid32bit=1
             =                       crc=1        finobt=0 spinodes=0
    data     =                       bsize=4096   blocks=5242880, imaxpct=25
             =                       sunit=0      swidth=0 blks
    naming   =version 2              bsize=4096   ascii-ci=0 ftype=1
    log      =internal               bsize=4096   blocks=2560, version=2
             =                       sectsz=512   sunit=0 blks, lazy-count=1
    realtime =none                   extsz=4096   blocks=0, rtextents=0
    data blocks changed from 5242880 to 7864320

Procedure 2: Create and format a partition

To use the new disk space to create a partition, follow these steps:

  1. Run the fdisk -u /dev/vdb command to create a partition.

    In this example, the new 20 GiB disk space is used to create a partition named /dev/vdb2.

    [root@localhost ~]# fdisk -u /dev/vdb
    Welcome to fdisk (util-linux 2.23.2).

    Changes will remain in memory only, until you decide to write them.
    Be careful before using the write command.
    Command (m for help): p

    Disk /dev/vdb: 42.9 GB, 42949672960 bytes, 83886080 sectors
    Units = sectors of 1 * 512 = 512 bytes
    Sector size (logical/physical): 512 bytes / 512 bytes
    I/O size (minimum/optimal): 512 bytes / 512 bytes
    Disk label type: dos
    Disk identifier: 0x2b31a2a3

       Device Boot      Start         End      Blocks   Id  System
    /dev/vdb1            2048    41943039    20970496   83  Linux

    Command (m for help): n
    Partition type:
       p   primary (1 primary, 0 extended, 3 free)
       e   extended
    Select (default p): p
    Partition number (2-4, default 2): 2
    First sector (41943040-83886079, default 41943040):
    Using default value 41943040
    Last sector, +sectors or +size{K,M,G} (41943040-83886079, default 83886079):
    Using default value 83886079
    Partition 2 of type Linux and of size 20 GiB is set

    Command (m for help): w
    The partition table has been altered!

    Calling ioctl() to re-read partition table.
    Syncing disks.
  2. Run the lsblk /dev/vdb command to view the partition.
    [root@localhost ~]# lsblk /dev/vdb
    NAME   MAJ:MIN RM SIZE RO TYPE MOUNTPOINT
    vdb    253:16   0  40G  0 disk
    ├─vdb1 253:17   0  20G  0 part
    └─vdb2 253:18   0  20G  0 part
  3. Format the new partition.
    • To create an ext4 file system, run the mkfs.ext4 /dev/vdb2 command.
      [root@localhost ~]# mkfs.ext4 /dev/vdb2
      mke2fs 1.42.9 (28-Dec-2013)
      Filesystem label=
      OS type: Linux
      Block size=4096 (log=2)
      Fragment size=4096 (log=2)
      Stride=0 blocks, Stripe width=0 blocks
      1310720 inodes, 5242880 blocks
      262144 blocks (5.00%) reserved for the super user
      First data block=0
      Maximum filesystem blocks=2153775104
      160 block groups
      32768 blocks per group, 32768 fragments per group
      8192 inodes per group
      Superblock backups stored on blocks:
              32768, 98304, 163840, 229376, 294912, 819200, 884736, 1605632, 2654208,
              4096000

      Allocating group tables: done
      Writing inode tables: done
      Creating journal (32768 blocks): done
      Writing superblocks and filesystem accounting information: done


      [root@localhost ~]# blkid /dev/vdb2
      /dev/vdb2: UUID="e3f336dc-d534-4fdd-af71-b6ff1a55bdbb" TYPE="ext4"
    • To create an ext3 file system, run the mkfs.ext3 /dev/vdb2 command.
      [root@localhost ~]# mkfs.ext3  /dev/vdb2
      mke2fs 1.42.9 (28-Dec-2013)
      Filesystem label=
      OS type: Linux
      Block size=4096 (log=2)
      Fragment size=4096 (log=2)
      Stride=0 blocks, Stripe width=0 blocks
      1310720 inodes, 5242880 blocks
      262144 blocks (5.00%) reserved for the super user
      First data block=0
      Maximum filesystem blocks=4294967296
      160 block groups
      32768 blocks per group, 32768 fragments per group
      8192 inodes per group
      Superblock backups stored on blocks:
              32768, 98304, 163840, 229376, 294912, 819200, 884736, 1605632, 2654208,
              4096000

      Allocating group tables: done
      Writing inode tables: done
      Creating journal (32768 blocks): done
      Writing superblocks and filesystem accounting information: done

      [root@localhost ~]# blkid /dev/vdb2
      /dev/vdb2: UUID="dd5be97d-a630-4593-9b0f-5056def914ea" SEC_TYPE="ext2" TYPE="ext3"
    • To create an XFS file system, run the mkfs.xfs -f /dev/vdb2 command.
      [root@localhost ~]# mkfs.xfs -f /dev/vdb2
      meta-data=/dev/vdb2              isize=512    agcount=4, agsize=1310720 blks
               =                       sectsz=512   attr=2, projid32bit=1
               =                       crc=1        finobt=0, sparse=0
      data     =                       bsize=4096   blocks=5242880, imaxpct=25
               =                       sunit=0      swidth=0 blks
      naming   =version 2              bsize=4096   ascii-ci=0 ftype=1
      log      =internal log           bsize=4096   blocks=2560, version=2
               =                       sectsz=512   sunit=0 blks, lazy-count=1
      realtime =none                   extsz=4096   blocks=0, rtextents=0

      [root@localhost ~]# blkid /dev/vdb2
      /dev/vdb2: UUID="66251477-3ae4-4b44-8b21-5604420dbecb" TYPE="xfs"
    • To create a TRFS file system, run the mkfs.btrfs /dev/vdb2 command.
      [root@localhost ~]# mkfs.btrfs /dev/vdb2
      btrfs-progs v4.9.1
      See http://btrfs.wiki.kernel.org for more information.

      Label:              (null)
      UUID:               6fb5779b-57d7-4aaf-bf09-82b46f54a429
      Node size:          16384
      Sector size:        4096
      Filesystem size:    20.00GiB
      Block group profiles:
        Data:             single            8.00MiB
        Metadata:         DUP               1.00GiB
        System:           DUP               8.00MiB
      SSD detected:       no
      Incompat features:  extref, skinny-metadata
      Number of devices:  1
      Devices:
         ID        SIZE  PATH
          1    20.00GiB  /dev/vdb2

      [root@localhost ~]# blkid /dev/vdb2
      /dev/vdb2: UUID="6fb5779b-57d7-4aaf-bf09-82b46f54a429" UUID_SUB="9bdd889a-ab69-4653-a583-d1b6b8723378" TYPE="btrfs"
  4. Run the mount /dev/vdb2 /mnt command to mount the file system.
  5. Run the df -h command to view the current disk space and usage.
    The information of the new file system is displayed, indicating that the file system is mounted and you can use it.
    [root@localhost ~]# df -h
    Filesystem Size Used Avail Use% Mounted on
    /dev/vda1 40G 1.6G 36G 5% /
    devtmpfs 3.9G 0 3.9G 0% /dev
    tmpfs 3.9G 0 3.9G 0% /dev/shm
    tmpfs 3.9G 460K 3.9G 1% /run
    tmpfs 3.9G 0 3.9G 0% /sys/fs/cgroup
    /dev/vdb2 9.8G 37M 9.2G 1% /mnt
    tmpfs 783M 0 783M 0% /run/user/0
