Lindorm Insight allows you to view the performance monitoring data of clusters. This provides an easy method for you to view the resource usage of clusters. The Request Distribution page displays the monitoring data of table read and write requests from multiple dimensions, such as IDC and group. On the page, you can view the top 10 items for each metric.

A compute unit (CU) in the Lindorm Insight system represents the resources that are consumed to scan 4 KB data. A larger number of CUs means that a larger amount of data is scanned. This computing method is generally used in Lindorm serverless services to check the amount of data that is scanned by users or tables.

Go to the Request Distribution page

Log on to the Lindorm Insight system. In the left-side navigation pane, choose Monitor > Request Distribution. Then, the Request Distribution page in Lindorm Insight appears. You can filter and view table read and write details by IDC, group, and time range, and view the top 10 items.

Distribution details of read and write requests
The Request Distribution page is divided into multiple sections. You can click the following links for the sections to view the corresponding data:

Table distribution of read requests

The Table distribution of read requests section displays the top 10 tables when the tables are ranked by the number of queries based on the specified dimensions.Table distribution of read requests

Distribution of read request CU user

The Distribution of read request CU user section displays the top 10 users when the users are ranked by the number of consumed CUs for read requests.Distribution of read request CU user

Distribution of read request CU table

The Distribution of read request CU table section displays the top 10 tables when the tables are ranked by the number of consumed CUs for read requests.Distribution of read request CU table

Table distribution of write requests

The Table distribution of write requests section displays the top 10 tables when the tables are ranked by the number of queries based on the specified dimensions.Table distribution of write requests

Distribution of write request CU user

The Distribution of write request CU user section displays the top 10 users when the users are ranked by the number of consumed CUs for write requests.Distribution of write request CU user

Distribution of write request CU table

The Distribution of write request CU table section displays the top 10 tables when the tables are ranked by the number of consumed CUs for write requests.Distribution of write request CU table
