Apsara File Storage NAS (NAS) is a file system service that is designed for computing services, such as Elastic Compute Service (ECS) instances, Elastic High Performance Computing (E-HPC) clusters, and Alibaba Cloud Container Service for Kubernetes (ACK) clusters. NAS provides seamless integration, storage sharing, and security management. NAS is suitable in scenarios where applications that are deployed on multiple ECS instances, E-HPC clusters, or ACK clusters need to access the same data source. This topic describes how to configure a shared NAS volume for training jobs.

Background information

Data scientists may need to keep their data or retrieve the same copy of training data. To meet this requirement, we recommend that you configure a shared NAS volume and mount it to the runtime where you use Arena to submit jobs. This prevents data loss because code and data stored in the shared NAS volume are not deleted with containers.

You can allow the developers in a team to share the same storage pool. If you have declared a shared NAS volume and specified the path that is used to mount the volume, the shared NAS volume is automatically mounted to the specified path. After the shared NAS volume is mounted, you can use data and code stored in the volume by specifying the --data parameter each time you submit a job.

In Kubernetes, storage volumes are declared by using persistent volumes (PVs) and persistent volume claims (PVCs). As the administrator of a Kubernetes cluster, you must create a PVC for each data scientist in your team. For example, User A and User B can mount their PVs to the same NAS volume or Cloud Paralleled File System (CPFS). However, the PVs must be mounted to different subdirectories to isolate the runtimes of User A and User B.

Step 1: Create a NAS file system

For more information about how to create a NAS file system, see Create a General-purpose NAS file system.
Note

Set the parameters based on the following descriptions:

  • Select General Purpose NAS as the file system type.
  • Select the region where the target ACK cluster is deployed.
  • Select NFS as the protocol type.

Step 2: Add a mount target

For more information about how to add a mount target, see Create a mount target.
Note
Set the parameters based on the following descriptions:
  • Select VPC Network as the type of the mount target.
  • Select the same Virtual Private Cloud (VPC) network and same VSwitches that are used in the target ACK cluster.
After the mount target is created, go to the Mount Target page and move the pointer over the Mount targetto view and copy the address of the mount target.The information of the mount target

Step 3: Create a PV and a PVC for the target ACK cluster

  1. Log on to the ACK console.
  2. Create a PV.
    For more information about how to create a PV, see Create a PV.
    Note When you configure the PV, set Mount Target Domain Name: to Select Mount Target, and select the address of mount target from the Select drop-down list.
  3. Create a PVC.
    For more information about how to create a PVC, see Create a PVC.
    After the PVC is created, you can find the created PVC in the PVC list.

Step 4: Upload data to the PV claimed by the PVC

Kubernetes clusters uses PVCs to access shared data (data stored in the NAS file system in this example). Therefore, you only need to upload the data and code to the NAS file system.

  1. Run the following command to log on to an ECS instance in the target ACK cluster:
    ssh root@39.10x.xx.xx
    Note Make sure that the ECS instance is deployed in the same VPC network where the NAS file system is deployed.
  2. Paste the mount command to the command-line interface and run the command to mount the NAS file system.
    The mount command is used to mount the NAS file system to the /mnt path of the ECS instance.Mount command
    sudo mount -t nfs -o xxxx.nas.aliyuncs.com:/ /mnt
  3. Run the following command to create two subdirectories for the mounted NAS file system: tf_data/ for storing the training data of TF mnist and pytorch_data/ for storing the training data of Pytorch mnist.
    cd /mnt/
    mkdir tf_data/
    mkdir pytorch_data/
  4. Run the following command to download the TF mnist dataset:
    cd tf_data
    git clone https://code.aliyun.com/xiaozhou/tensorflow-sample-code.git
    mv tensorflow-sample-code/data/* ./ && rm -rf tensorflow-sample-code
  5. Run the following command to download the Pytorch mnist dataset:
    cd pytorch_data
    git clone https://code.aliyun.com/370272561/mnist-pytorch.git
    mv mnist-pytorch/MNIST ./ && rm -rf mnist-pytorch
