ApsaraDB for Redis:ApsaraDB for Redis Community Edition performance whitepaper

Last Updated:Nov 07, 2023

This topic describes the test environment, test tool, test method, and test results of an ApsaraDB for Redis performance test.

Test environment

Database

Item

Description

Region and zone

Zone A in the China (Zhangjiakou) region

Minor engine version

Redis 6.0.2.5

Instance architecture

Standard master-replica architecture for which the cluster mode is disabled. For more information, see Standard architecture.

Instance specifications

The test results are only slightly affected by instance specifications. In this example, the 4 GB (redis.shard.large.ce) specification is used. For more information, see Specifications of ApsaraDB for Redis Community Edition instances.

Test client

Item

Description

Host of the client

Elastic Compute Service (ECS) instance of the ecs.g5ne.16xlarge instance type. For more information, see Overview of instance families.

Region and zone

Zone A in the China (Zhangjiakou) region

Operating system

CentOS 7.2 64-bit

Network

The client is in the same virtual private cloud (VPC) as the Redis instance and is connected to the Redis instance over the VPC.

Test tool

The redis-benchmark tool is used for stress testing. It is an official performance testing tool provided by Redis to effectively measure the performance of Redis. The redis-benchmark version used in this test is 7.2.0.

Procedure

Download the Redis source code on the ECS instance and compile the code to generate a redis-benchmark file and start the test. For more information, see Use redis-cli to connect to an ApsaraDB for Redis instance.

For example, to test the execution performance of the SET command, you can use the following sample command. The sample command executes the SET command by using 16 threads and 256 connections, and then generates 3,000,000 key-value pairs. Each value has a size of up to 64 bytes.

./src/redis-benchmark -h r-bp1s02ae14mr****.redis.rds.aliyuncs.com -p 6379 -a testaccount:Rp829dlwa -n 3000000 -r 10000000  -c 256 -t set -d 64 --threads 16
Table 1. Parameters

Parameter

Description

-h

The internal endpoint of the Redis instance. For more information, see View endpoints.

-p

The service port of the Redis instance. Default value: 6379.

-a

The password used to connect to the Redis instance.

Note

If you use an account created in the ApsaraDB for Redis console to connect to the Redis instance, the password must be in the <user>:<password> format. For example, if the username of the account is admin and the password is Rp829dlwa, use admin:Rp829dlwa as the password to connect to the Redis instance.

-c

The number of concurrent connections.

-n

The total number of requests tested. Set this parameter to a large value to ensure continuous stress testing.

-t

The tested commands, such as SET and GET.

-d

The data size of the value manipulated by a command such as SET. Unit: bytes.

-r

The random range of keys that you want to use. This parameter specifies how many unique keys are used during the benchmarking test.

--threads

Runs a multi-threaded stress test and specifies the number of threads.

Note

For more information about the parameters, see redis-benchmark.

Test results

This section describes the test metrics and test results of a performance test on more than a dozen basic commands of Redis such as SET and GET. The performance test is conducted in different scenarios with different numbers of threads and data sizes for write operations.

Test metrics

Test metric

Description

QPS

The number of read and write operations that are processed per second.

Latency

The average latency for a specific proportion of operations. Unit: milliseconds.

99th Percentile Latency

The maximum latency of 99% of the operations. Unit: milliseconds. For example, a value of 0.5 indicates that 99% of requests can be processed within 0.5 milliseconds.

Strings

  • GET

    Sample command:

    ./src/redis-benchmark -h r-bp1s02ae14mr****.redis.rds.aliyuncs.com -p 6379 -a testaccount:Rp829dlwa -t get -d 16 --threads 4 -c 100 -n 3000000 -r 30000000

    Results

    Value length (bytes)

    QPS

    Average latency (milliseconds)

    99th percentile latency (milliseconds)

    16

    199653.94

    0.483

    0.959

    128

    187488.28

    0.499

    1.055

    256

    187195.81

    0.514

    1.015

    1024

    178826.91

    0.544

    1.071

    2048

    100677.90

    0.966

    1.487

  • SET

    Sample command:

    ./src/redis-benchmark -h r-bp1s02ae14mr****.redis.rds.aliyuncs.com -p 6379 -a testaccount:Rp829dlwa -t set -d 16 --threads 2 -c 150 -n 3000000 -r 30000000

    Results

    Value length (bytes)

    QPS

    Average latency (milliseconds)

    99th percentile latency (milliseconds)

    16

    133291.86

    1.070

    1.863

    128

    119779.61

    1.196

    2.039

    256

    107096.96

    1.341

    2.191

    1024

    84319.41

    1.701

    3.327

    2048

    54911.87

    2.676

    11.383

    Note

    The maximum bandwidth of the instance type is 96 Mbit/s. This indicates that if the value length is 1,024 bytes, the maximum network bandwidth is reached.

  • MSET

    Sample command:

    ./src/redis-benchmark -h r-bp1s02ae14mr****.redis.rds.aliyuncs.com -p 6379 -a testaccount:Rp829dlwa -t mset -d 16 --threads 2 -c 100 -n 3000000 -r 30000000

    Results

    Value length (bytes)

    QPS

    Average latency (milliseconds)

    99th percentile latency (milliseconds)

    16

    41120.11

    2.364

    5.167

  • INCR

    Sample command:

    ./src/redis-benchmark -h r-bp1s02ae14mr****.redis.rds.aliyuncs.com -p 6379 -a testaccount:Rp829dlwa -t incr --threads 2 -c 150 -n 3000000 -r 30000000

    Results

    QPS

    Average latency (milliseconds)

    99th percentile latency (milliseconds)

    146092.05

    0.978

    1.687

Lists

  • LPUSH

    Sample command:

    ./src/redis-benchmark -h r-bp1s02ae14mr****.redis.rds.aliyuncs.com -p 6379 -a testaccount:Rp829dlwa -t lpush -d 16 --threads 2 -c 100 -n 3000000 -r 30000000

    Results

    Value length (bytes)

    QPS

    Average latency (milliseconds)

    99th percentile latency (milliseconds)

    16

    153830.38

    0.623

    1.191

    128

    142619.44

    0.669

    1.239

    256

    122249.38

    0.782

    1.431

    1024

    92267.95

    1.082

    1.775

  • LPOP

    Sample command:

    ./src/redis-benchmark -h r-bp1s02ae14mr****.redis.rds.aliyuncs.com -p 6379 -a testaccount:Rp829dlwa -t lpop -d 16 --threads 2 -c 100 -n 3000000 -r 30000000

    Results

    Value length (bytes)

    QPS

    Average latency (milliseconds)

    99th percentile latency (milliseconds)

    16

    161908.36

    0.601

    1.143

    128

    155593.59

    0.622

    1.167

    256

    146106.27

    0.664

    1.239

    1024

    123492.37

    0.786

    1.407

  • RPUSH

    Sample command:

    ./src/redis-benchmark -h r-bp1s02ae14mr****.redis.rds.aliyuncs.com -p 6379 -a testaccount:Rp829dlwa -t rpush -d 16 --threads 2 -c 100 -n 3000000 -r 30000000

    Results

    Value length (bytes)

    QPS

    Average latency (milliseconds)

    99th percentile latency (milliseconds)

    16

    153594.11

    0.620

    1.135

    128

    142626.22

    0.668

    1.247

    256

    127448.07

    0.751

    1.327

    1024

    93583.30

    1.029

    1.703

  • RPOP

    Sample command:

     ./src/redis-benchmark -h r-bp1s02ae14mr****.redis.rds.aliyuncs.com -p 6379 -a testaccount:Rp829dlwa -t rpop -d 16 --threads 2 -c 100 -n 3000000 -r 30000000

    Results

    Value length (bytes)

    QPS

    Average latency (milliseconds)

    99th percentile latency (milliseconds)

    16

    168719.42

    0.576

    1.127

    128

    164122.77

    0.592

    1.143

    256

    157637.53

    0.611

    1.167

    1024

    128816.18

    0.755

    1.367

Sets

  • SADD

    Sample command:

    ./src/redis-benchmark -h r-bp1s02ae14mr****.redis.rds.aliyuncs.com -p 6379 -a testaccount:Rp829dlwa -t sadd --threads 2 -c 150 -n 3000000 -r 30000000

    Results

    QPS

    Average latency (milliseconds)

    99th percentile latency (milliseconds)

    136134.67

    1.045

    1.735

  • SPOP

    Sample command:

    ./src/redis-benchmark -h r-bp1s02ae14mr****.redis.rds.aliyuncs.com -p 6379 -a testaccount:Rp829dlwa -t spop --threads 2 -c 150 -n 3000000 -r 30000000

    Results

    QPS

    Average latency (milliseconds)

    99th percentile latency (milliseconds)

    108053.59

    1.329

    2.383

Zsets

  • ZADD

    Sample command:

    ./src/redis-benchmark -h r-bp1s02ae14mr****.redis.rds.aliyuncs.com -p 6379 -a testaccount:Rp829dlwa -t zadd --threads 2 -c 150 -n 3000000 -r 30000000

    Results

    QPS

    Average latency (milliseconds)

    99th percentile latency (milliseconds)

    86770.40

    1.654

    2.423

  • ZPOPMIN

    Sample command:

    ./src/redis-benchmark -h r-bp1s02ae14mr****.redis.rds.aliyuncs.com -p 6379 -a testaccount:Rp829dlwa -t zpopmin --threads 2 -c 150 -n 3000000 -r 30000000

    Results

    QPS

    Average latency (milliseconds)

    99th percentile latency (milliseconds)

    104286.16

    1.378

    2.127

Hashes

  • HSET

    Sample command:

    ./src/redis-benchmark -h r-bp1s02ae14mr****.redis.rds.aliyuncs.com -p 6379 -a testaccount:Rp829dlwa -t hset -d 16 --threads 2 -c 150 -n 3000000 -r 30000000

    Results

    Value length (bytes)

    QPS

    Average latency (milliseconds)

    99th percentile latency (milliseconds)

    16

    121163.16

    1.184

    1.951

    128

    110905.73

    1.291

    2.023

    256

    105995.84

    1.347

    2.127

    1024

    76242.76

    1.900

    3.359
